Артикул
Название
Примечание
Количество
|$0
6138-72-1120
INJECTION PUMP ASS'Y
SN: 50202-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453,0465,0466,0473,0483 AND 0493.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105210-4690
FEED PUMP ASS'Y
SN: 50202-UP
1шт.
1
DK152051-0020
HOUSING
SN: 50202-UP
1шт.
2
DK152100-1120
PISTON
SN: 50202-UP
1шт.
4
DK152105-1500
PLUG
SN: 50202-UP
1шт.
6
DK152111-2920
TAPPET ASS'Y
SN: 50202-UP
1шт.
7
DK152112-0100
ROLLER
SN: 50202-UP
1шт.
8
DK152113-0100
PIN
SN: 50202-UP
1шт.
9
DK152114-0700
GUIDE
SN: 50202-UP
2шт.
12
DK152117-0100
PLUG
SN: 50202-UP
1шт.
15
DK152121-0200
RING,SNAP
SN: 50202-UP
1шт.
17
DK152300-5920
BOLT,EYE
SN: 50202-UP
1шт.
|$0
6138-72-1120
INJECTION PUMP ASS'Y
SN: 50202-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453,0465,0466,0473,0483 AND 0493.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105210-4690
FEED PUMP ASS'Y
SN: 50202-UP
1шт.
1
DK152051-0020
HOUSING
SN: 50202-UP
1шт.
2
DK152100-1120
PISTON
SN: 50202-UP
1шт.
4
DK152105-1500
PLUG
SN: 50202-UP
1шт.
6
DK152111-2920
TAPPET ASS'Y
SN: 50202-UP
1шт.
7
DK152112-0100
ROLLER
SN: 50202-UP
1шт.
8
DK152113-0100
PIN
SN: 50202-UP
1шт.
9
DK152114-0700
GUIDE
SN: 50202-UP
2шт.
12
DK152117-0100
PLUG
SN: 50202-UP
1шт.
15
DK152121-0200
RING,SNAP
SN: 50202-UP
1шт.
17
DK152300-5920
BOLT,EYE
SN: 50202-UP
1шт.
Выбрано товаров: 48
