Запчасти Komatsu SA6D110-1F ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|1

6138-72-1600

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0491.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105411-0840

GOVERNOR ASS'Y

SN: 50001-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.

-1шт.

1

DK154000-6400

HOUSING

SN: 50001-UP

1шт.

2

DK029632-5070

O-RING

SN: 50001-UP

1шт.

3

DK154007-2900

PLUG

SN: 50001-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 50001-UP

1шт.

5

DK020018-1840

BOLT

SN: 50001-UP

1шт.

6

DK154350-1900

PLATE

SN: 50001-UP

1шт.

7

DK029010-6810

BOLT

SN: 50001-UP

6шт.

8

DK154010-0100

SCREW

SN: 50001-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 50001-UP

1шт.

10

DK154012-2220

BOLT

SN: 50001-UP

1шт.

11

DK014110-8440

WASHER,SPRING

SN: 50001-UP

1шт.

12

DK155404-5700

CAP

SN: 50001-UP

1шт.

13

DK154100-9720

FLYWEIGHT ASS'Y

SN: 50001-UP

1шт.

14

DK025803-1610

KEY¤ 16MM

SN: 50001-UP

1шт.

15

DK029321-2020

WASHER,SPRING

SN: 50001-UP

1шт.

16

DK029231-2030

NUT

SN: 50001-UP

1шт.

17

DK154123-0120

SLEEVE

SN: 50001-UP

1шт.

18

DK029311-0010

SHIM¤ 0.20MM

SN: 50001-UP

-2шт.

|18

DK029311-0180

SHIM¤ 0.30MM

SN: 50001-UP

-2шт.

|18

DK029311-0190

SHIM¤ 0.40MM

SN: 50001-UP

-2шт.

|18

DK139410-0000

SHIM¤ 0.50MM

SN: 50001-UP

-2шт.

|18

DK029311-0210

SHIM¤ 1.00MM

SN: 50001-UP

-2шт.

|18

DK139410-0100

SHIM¤ 1.50MM

SN: 50001-UP

-2шт.

|18

DK139410-3000

SHIM¤ 2.00MM

SN: 50001-UP

-2шт.

|18

DK139410-3100

SHIM¤ 3.00MM

SN: 50001-UP

-2шт.

|18

DK139410-3200

SHIM¤ 4.00MM

SN: 50001-UP

-2шт.

19

DK154154-0701

SPRING

SN: 50001-UP

1шт.

20

DK154177-0220

CAPSULE,SPRING

SN: 50001-UP

1шт.

21

DK029201-6010

NUT

SN: 50001-UP

1шт.

22

DK154211-4220

GUIDE LEVER ASS'Y

SN: 50001-UP

1шт.

23

DK029310-5170

SHIM

SN: 50001-UP

3шт.

24

DK025520-1210

PIN,SPLIT

SN: 50001-UP

3шт.

25

DK154230-0120

LINK

SN: 50001-UP

1шт.

26

DK154236-4100

LEVER,TENSION

SN: 50001-UP

1шт.

27

DK155412-5200

IMPELLER

SN: 50001-UP

1шт.

28

DK154350-7700

GASKET

SN: 50001-UP

1шт.

29

DK154401-0120

LEVER

SN: 50001-UP

1шт.

30

DK154401-1120

LINK

SN: 50001-UP

1шт.

31

DK016010-0540

RING,SNAP

SN: 50001-UP

1шт.

32

DK154222-6200

PIN

SN: 50001-UP

1шт.

33

DK029300-4010

WASHER

SN: 50001-UP

1шт.

34

DK016010-0440

RING,SNAP

SN: 50001-UP

1шт.
