Артикул
Название
Примечание
Количество
|1
6222-75-1270
INJECTION PUMP A.
SN: 10001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2F8 TO A4010-G2F8.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND092100-2491
FEED PUMP ASS'Y
SN: 10001-UP
1шт.
1
ND092120-0630
HOUSING,FEED PUMP
SN: 10001-UP
1шт.
2
ND092168-0160
ROD,PUSH
SN: 10001-UP
1шт.
6
ND092126-0010
PLUG
SN: 10001-UP
3шт.
8
ND092171-0011
PISTON
SN: 10001-UP
1шт.
9
ND092173-0010
SPRING,TAPPET
SN: 10001-UP
1шт.
10
ND092174-0050
TAPPET
SN: 10001-UP
1шт.
11
ND092176-0010
ROLLER,TAPPET
SN: 10001-UP
1шт.
12
ND092178-0040
PIN
SN: 10001-UP
1шт.
13
ND092179-0070
BLOCK,SLIDING
SN: 10001-UP
2шт.
14
ND092182-0060
SPRING,PISTON
SN: 10001-UP
1шт.
15
ND092184-0021
PLUG
SN: 10001-UP
1шт.
17
ND092223-0070
SCREW
SN: 10001-UP
1шт.
20
ND949072-0940
RING,SNAP
SN: 10001-UP
1шт.
22
ND949181-0420
NIPPLE,EYE
SN: 10001-UP
1шт.
23
ND090081-0011
COVER,PRIMMING PUMP
SN: 10001-UP
1шт.
Выбрано товаров: 27
