Артикул
Название
Примечание
Количество
|1
6222-75-1270
INJECTION PUMP A.
SN: 10001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2F9 TO A4010-G2F9.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND190800-6850
GOVERNOR ASS'Y
SN: 10001-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D2F9 AND A4010-E2F9.
-1шт.
1
ND091010-1270
COVER,GOVERNOR
SN: 10001-UP
1шт.
2
ND949050-3390
NUT
SN: 10001-UP
1шт.
4
ND090991-0090
PLUG,SCREW
SN: 10001-UP
2шт.
5
ND090560-0140
CAPSULE,FULL STOP
SN: 10001-UP
1шт.
6
ND091031-0030
NUT,CAP
SN: 10001-UP
1шт.
7
ND949047-1190
BOLT
SN: 10001-UP
1шт.
8
ND090880-0110
LEVER,SWIVEL
SN: 10001-UP
1шт.
11
ND949071-0090
WASHER,SNAP
SN: 10001-UP
2шт.
12
ND949047-1760
BOLT
SN: 10001-UP
4шт.
13
ND949047-2340
BOLT
SN: 10001-UP
2шт.
15
ND091071-1420
LEVER,ADJUST
SN: 10001-UP
1шт.
17
ND091090-1410
LEVER,STOP
SN: 10001-UP
1шт.
18
ND949047-2701
BOLT
SN: 10001-UP
2шт.
19
ND091051-0930
PLATE
SN: 10001-UP
1шт.
20
ND090923-0060
NUT,ADAPTER LOCK
SN: 10001-UP
1шт.
21
ND091071-3690
LEVER,ADJUST
SN: 10001-UP
1шт.
23
ND091038-0040
SPRING,OUTER PRESSURE
SN: 10001-UP
1шт.
24
ND949140-6170
O-RING
SN: 10001-UP
1шт.
25
ND091016-0360
BUSHING,BEARING
SN: 10001-UP
1шт.
26
ND091043-0010
COVER,SPRING
SN: 10001-UP
1шт.
27
ND091038-0050
SPRING,OUTER PRESSURE
SN: 10001-UP
1шт.
28
ND091035-0240
SHAFT,GOVERNOR
SN: 10001-UP
1шт.
29
ND091036-0010
CUP,SPRING
SN: 10001-UP
1шт.
30
ND091034-0130
LEVER,SUPPORT
SN: 10001-UP
1шт.
31
ND91418-06161
BOLT
SN: 10001-UP
2шт.
32
ND091033-0030
PLATE,CAP
SN: 10001-UP
1шт.
33
ND091038-0030
SPRING,OUTER PRESSURE
SN: 10001-UP
1шт.
34
ND949130-0030
KEY
SN: 10001-UP
1шт.
35
ND090241-0010
WASHER¤ 1.6MM
SN: 10001-UP
2шт.
36
ND91418-06201
BOLT
SN: 10001-UP
5шт.
37
ND091042-0010
SPRING,RETURN
SN: 10001-UP
1шт.
38
ND949013-8210
WASHER¤ 0.3MM
SN: 10001-UP
-2шт.
|38
ND949013-8220
WASHER¤ 0.6MM
SN: 10001-UP
-2шт.
|38
ND949013-8230
WASHER¤ 0.9MM
SN: 10001-UP
-2шт.
40
ND090821-0171
STOPPER
SN: 10001-UP
1шт.
41
ND949053-0140
NUT
SN: 10001-UP
1шт.
42
ND091031-0042
NUT,CAP
SN: 10001-UP
1шт.
43
ND949018-1020
WASHER¤ 1.0MM
SN: 10001-UP
4шт.
44
ND91418-06141
BOLT
SN: 10001-UP
1шт.
45
ND091031-0151
NUT,CAP
SN: 10001-UP
1шт.
46
ND090944-0310
BUSHING
SN: 10001-UP
1шт.
Выбрано товаров: 54
