Артикул
Название
Примечание
Количество
|1
6222-75-1270
INJECTION PUMP A.
SN: 10001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2F7 TO A4010-G2F7.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND190100-1301
BODY ASS'Y
SN: 10001-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2F7 AND A4010-C2F7.
-1шт.
1
ND090110-5290
HOUSING
SN: 10001-UP
1шт.
2
ND949043-0010
STUD
SN: 10001-UP
3шт.
4
ND090191-1500
CAMSHAFT
SN: 10001-UP
1шт.
6
ND090193-0050
RING,ADJUST
SN: 10001-UP
1шт.
7
ND090194-0410
PLATE¤ 0.03MM
SN: 10001-UP
-2шт.
|7
ND090194-0070
PLATE¤ 0.1MM
SN: 10001-UP
-2шт.
|7
ND090194-0080
PLATE¤ 0.15MM
SN: 10001-UP
-2шт.
|7
ND090194-0090
PLATE¤ 0.3MM
SN: 10001-UP
-2шт.
|7
ND090194-0100
PLATE¤ 0.5MM
SN: 10001-UP
-2шт.
|7
ND090194-0340
PLATE¤ 0.12MM
SN: 10001-UP
-2шт.
|7
ND090194-0350
PLATE¤ 0.14MM
SN: 10001-UP
-2шт.
|7
ND090194-0360
PLATE¤ 0.18MM
SN: 10001-UP
-2шт.
9
ND090201-0430
COVER,BEARING
SN: 10001-UP
1шт.
10
ND91518-06161
BOLT
SN: 10001-UP
4шт.
12
ND090361-0180
BEARING,CENTER
SN: 10001-UP
1шт.
13
ND949006-7300
SCREW
SN: 10001-UP
2шт.
14
ND090248-0010
WASHER
SN: 10001-UP
2шт.
15
ND090215-0060
SCREW
SN: 10001-UP
1шт.
16
ND090317-0140
PLUG,SCREW
SN: 10001-UP
1шт.
18
ND090193-0060
RING,ADJUST
SN: 10001-UP
1шт.
21
ND090194-0420
PLATE¤ 0.03MM
SN: 10001-UP
-2шт.
|21
ND090194-0300
PLATE¤ 0.1MM
SN: 10001-UP
-2шт.
|21
ND090194-0310
PLATE¤ 0.16MM
SN: 10001-UP
-2шт.
|21
ND090194-0320
PLATE¤ 0.3MM
SN: 10001-UP
-2шт.
|21
ND090194-0330
PLATE¤ 0.5MM
SN: 10001-UP
-2шт.
|21
ND090194-0370
PLATE¤ 0.12MM
SN: 10001-UP
-2шт.
|21
ND090194-0380
PLATE¤ 0.14MM
SN: 10001-UP
-2шт.
25
ND90160-06051
NUT
SN: 10001-UP
3шт.
26
ND90258-06001
WASHER,SPRING
SN: 10001-UP
3шт.
29
ND90458-06750
KEY
SN: 10001-UP
1шт.
30
ND090012-0340
NUT
SN: 10001-UP
1шт.
Выбрано товаров: 49
