Запчасти Komatsu SA6D108-1D ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)(№-) ДВИГАТЕЛЬ

|1

6222-75-1261

INJECTION PUMP A.

SN: 21144-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2B9 TO A4010-J2B9.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-5700

GOVERNOR ASS'Y

SN: 21144-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-F2B9 AND A4010-G2B9.

-1шт.

1

ND091010-1270

COVER,GOVERNOR

SN: 21144-UP

1шт.

2

ND949050-3390

NUT

SN: 21144-UP

1шт.

3

ND090989-0010

SHAFT,LEVER SUPPORT

SN: 21144-UP

1шт.

4

ND090991-0090

PLUG,SCREW

SN: 21144-UP

2шт.

5

ND090560-0140

CAPSULE,FULL STOP

SN: 21144-UP

1шт.

6

ND091031-0030

NUT,CAP

SN: 21144-UP

1шт.

7

ND949047-1190

BOLT

SN: 21144-UP

1шт.

8

ND090880-0110

LEVER,SWIVEL

SN: 21144-UP

1шт.

9

ND090892-0160

BUSHING,LEVER

SN: 21144-UP

2шт.

10

ND949140-5760

O-RING

SN: 21144-UP

2шт.

11

ND949071-0090

WASHER,SNAP

SN: 21144-UP

2шт.

12

ND949047-1760

BOLT

SN: 21144-UP

4шт.

13

ND949047-2340

BOLT

SN: 21144-UP

2шт.

14

ND949150-2690

SEAL,OIL

SN: 21144-UP

1шт.

15

ND091071-1420

LEVER,ADJUST

SN: 21144-UP

1шт.

16

ND091094-0060

CAP,LEVER

SN: 21144-UP

1шт.

17

ND091090-1410

LEVER,STOP

SN: 21144-UP

1шт.

18

ND949047-2701

BOLT

SN: 21144-UP

2шт.

19

ND091051-0930

PLATE

SN: 21144-UP

1шт.

20

ND090923-0060

NUT,ADAPTER LOCK

SN: 21144-UP

1шт.

21

ND091071-3690

LEVER,ADJUST

SN: 21144-UP

1шт.

22

ND949062-1270

PACKING

SN: 21144-UP

1шт.

23

ND091038-0040

SPRING,OUTER PRESSURE

SN: 21144-UP

1шт.

24

ND949140-6170

O-RING

SN: 21144-UP

1шт.

25

ND091016-0360

BUSHING,BEARING

SN: 21144-UP

1шт.

26

ND091043-0010

COVER,SPRING

SN: 21144-UP

1шт.

27

ND091038-0050

SPRING,OUTER PRESSURE

SN: 21144-UP

1шт.

28

ND091035-0240

SHAFT,GOVERNOR

SN: 21144-UP

1шт.

29

ND091036-0010

CUP,SPRING

SN: 21144-UP

1шт.

30

ND091034-0130

LEVER,SUPPORT

SN: 21144-UP

1шт.

31

ND91418-06161

BOLT

SN: 21144-UP

2шт.

32

ND091033-0030

PLATE,CAP

SN: 21144-UP

1шт.

33

ND091038-0030

SPRING,OUTER PRESSURE

SN: 21144-UP

1шт.

34

ND949130-0030

KEY

SN: 21144-UP

1шт.

35

ND090241-0010

WASHER¤ 1.6MM

SN: 21144-UP

2шт.

36

ND91418-06201

BOLT

SN: 21144-UP

2шт.

37

ND091042-0010

SPRING,RETURN

SN: 21144-UP

1шт.

38

ND949013-8210

WASHER¤ 0.3MM

SN: 21144-UP

-2шт.

|38

ND949013-8220

WASHER¤ 0.6MM

SN: 21144-UP

-2шт.

|38

ND949013-8230

WASHER¤ 0.9MM

SN: 21144-UP

-2шт.

39

ND090944-0440

BUSHING

SN: 21144-UP

1шт.

40

ND090821-0171

STOPPER

SN: 21144-UP

1шт.

41

ND949053-0140

NUT

SN: 21144-UP

1шт.

42

ND091031-0042

NUT,CAP

SN: 21144-UP

1шт.

43

ND949018-1020

WASHER¤ 1.0MM

SN: 21144-UP

4шт.

44

ND91418-06141

BOLT

SN: 21144-UP

1шт.

45

ND091031-0151

NUT,CAP

SN: 21144-UP

1шт.

46

ND090944-0310

BUSHING

SN: 21144-UP

1шт.

47

ND949140-5740

O-RING

SN: 21144-UP

1шт.
