Запчасти Komatsu SA6D108-1D ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)(№-) ДВИГАТЕЛЬ

|1

6222-75-1261

INJECTION PUMP A.

SN: 21144-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2B9 TO A4010-J2B9.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-5700

GOVERNOR ASS'Y

SN: 21144-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-F2B9 AND A4010-G2B9.

-1шт.

1

ND090810-0620

HOUSING

SN: 21144-UP

1шт.

2

ND090878-0200

PLATE

SN: 21144-UP

1шт.

3

ND091024-0031

SCREW,ADJUSTING

SN: 21144-UP

1шт.

4

ND090901-0150

LEVER ASS'Y,TENSION

SN: 21144-UP

1шт.

5

ND090940-0480

LEVER ASS'Y,CONTROL

SN: 21144-UP

1шт.

6

ND90400-02101

E-RING,SPLIT

SN: 21144-UP

1шт.

7

ND090959-0010

LEVER ASS'Y,GUIDE

SN: 21144-UP

1шт.

8

ND090894-0010

E-RING

SN: 21144-UP

1шт.

9

ND090987-0010

SHIM

SN: 21144-UP

1шт.

10

ND948053-0051

NUT

SN: 21144-UP

1шт.

11

ND091046-0010

SLIDER,SUPPORT

SN: 21144-UP

1шт.

12

ND090970-0390

SHACKLE

SN: 21144-UP

1шт.

13

ND949100-0010

BEARING,BALL

SN: 21144-UP

1шт.

14

ND090840-0720

FLYWEIGHT ASS'Y

SN: 21144-UP

1шт.

15

ND949015-0500

WASHER¤ 2.5MM,SPRING

SN: 21144-UP

1шт.

16

ND090844-0010

NUT

SN: 21144-UP

1шт.

17

ND090861-0010

SLEEVE,GOVERNOR

SN: 21144-UP

1шт.

18

ND949013-4090

WASHER¤ 0.1MM

SN: 21144-UP

-2шт.

|18

ND949013-4060

WASHER¤ 0.2MM

SN: 21144-UP

-2шт.

|18

ND949013-4070

WASHER¤ 0.3MM

SN: 21144-UP

-2шт.

|18

ND949013-4080

WASHER¤ 0.4MM

SN: 21144-UP

-2шт.

|18

ND949013-4100

WASHER¤ 1.0MM

SN: 21144-UP

-2шт.

19

ND090992-0790

SPRING,CONTROL

SN: 21144-UP

1шт.

20

ND090993-0270

SPRING,START

SN: 21144-UP

1шт.

21

ND091006-0150

SCREW

SN: 21144-UP

1шт.

22

ND090119-0160

GASKET

SN: 21144-UP

1шт.

23

ND090823-0022

GASKET

SN: 21144-UP

1шт.

24

ND090894-0070

E-RING

SN: 21144-UP

1шт.

25

ND192600-0990

COMPENSATOR SUB A.,BOOST

SN: 21144-UP

1шт.

26

ND949140-4670

O-RING

SN: 21144-UP

1шт.

27

ND949056-3860

NUT

SN: 21144-UP

2шт.

28

ND192650-0010

LEVER SUB ASS'Y

SN: 21144-UP

1шт.

29

ND192653-0010

SHAFT,LEVER

SN: 21144-UP

1шт.

30

ND90577-05000

E-RING

SN: 21144-UP

2шт.

31

ND949013-3150

WASHER

SN: 21144-UP

5шт.

32

ND192654-0010

SPRING

SN: 21144-UP

1шт.

33

ND192646-0010

SPRING

SN: 21144-UP

1шт.

34

ND192648-0010

GASKET

SN: 21144-UP

1шт.

35

ND192640-0010

HOUSING SUB ASS'Y

SN: 21144-UP

1шт.

36

ND091094-0080

CAP

SN: 21144-UP

1шт.

37

ND091167-0110

SCREW

SN: 21144-UP

1шт.

38

ND949018-1020

WASHER¤ 1.0MM

SN: 21144-UP

1шт.

39

ND91418-06141

BOLT

SN: 21144-UP

2шт.

40

ND949047-1790

BOLT

SN: 21144-UP

2шт.

41

ND090222-0120

WASHER

SN: 21144-UP

2шт.

42

ND949180-0060

SCREW

SN: 21144-UP

1шт.

43

ND949181-0430

JOINT

SN: 21144-UP

1шт.

44

ND949002-0590

SCREW

SN: 21144-UP

1шт.

45

ND949047-6890

BOLT

SN: 21144-UP

4шт.

46

ND949047-6900

BOLT

SN: 21144-UP

1шт.

47

ND949047-6910

BOLT

SN: 21144-UP

1шт.

48

ND090921-0020

WASHER

SN: 21144-UP

2шт.
