Запчасти Komatsu SA6D108-1A-7 ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

6222-71-1120

INJECTION PUMP A.

SN: 10001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2A4 TO A4010-F2A4.

-1шт.

|$4

ND190800-2580

GOVERNOR ASS'Y

SN: 10001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D2A4 AND A4010-E2A4.

-1шт.

1

ND190890-0130

COVER

SN: 10001-UP

1шт.

2

ND091031-0150

NUT,CAP

SN: 10001-UP

1шт.

3

ND091006-0150

SCREW,ADJUSTING

SN: 10001-UP

1шт.

4

ND090944-0310

BUSHING

SN: 10001-UP

1шт.

5

ND090989-0010

SHAFT,LEVER SUPPORT

SN: 10001-UP

1шт.

6

ND090991-0010

PLUG

SN: 10001-UP

2шт.

7

ND090560-0200

CAPSULE,FULL STOP

SN: 10001-UP

1шт.

8

ND090923-0060

NUT

SN: 10001-UP

1шт.

9

ND090892-0160

BUSHING,LEVER

SN: 10001-UP

2шт.

10

ND949140-5760

O-RING

SN: 10001-UP

2шт.

|$16

ND090910-1390

ADAPTER ASS'Y

SN: 10001-UP

1шт.

11

ND090911-0010

SCREW,ADAPTER

SN: 10001-UP

1шт.

12

ND090919-0010

ADAPTER

SN: 10001-UP

1шт.

13

ND090918-2250

SPRING,GOVERNOR

SN: 10001-UP

1шт.

14

ND090894-0010

E-RING

SN: 10001-UP

1шт.

15

ND949013-3880

WASHER, 0.1MM

SN: 10001-UP

-2шт.

15

ND949013-4040

WASHER, 0.2MM

SN: 10001-UP

-2шт.

15

ND949013-4020

WASHER, 0.25MM

SN: 10001-UP

-2шт.

15

ND949013-4030

WASHER, 0.5MM

SN: 10001-UP

-2шт.

15

ND949013-7880

WASHER, 1.0MM

SN: 10001-UP

-2шт.

16

ND090923-0011

NUT,ADAPTER LOCK

SN: 10001-UP

1шт.

17

ND949047-1760

BOLT

SN: 10001-UP

4шт.

18

ND949047-1750

BOLT

SN: 10001-UP

2шт.

19

ND949150-2690

SEAL,OIL

SN: 10001-UP

1шт.

20

ND091071-1420

LEVER,ADJUSTING

SN: 10001-UP

1шт.

21

ND091071-4110

LEVER,ADJUSTING

SN: 10001-UP

1шт.

22

ND949047-1190

BOLT

SN: 10001-UP

1шт.

23

ND091094-0060

CAP,LEVER

SN: 10001-UP

1шт.

24

ND91418-06161

BOLT

SN: 10001-UP

2шт.

25

ND091050-0410

PLATE,COVER

SN: 10001-UP

1шт.

26

ND949047-2700

BOLT

SN: 10001-UP

2шт.

27

ND91418-06201

BOLT

SN: 10001-UP

2шт.

28

ND090241-0010

WASHER, 1.6MM

SN: 10001-UP

2шт.

29

ND091031-0030

NUT,CAP

SN: 10001-UP

1шт.

30

ND949062-1270

PACKING,RUBBER PLATE

SN: 10001-UP

1шт.

31

ND090944-0440

BUSHING

SN: 10001-UP

1шт.

32

ND949013-8210

WASHER, 0.3MM

SN: 10001-UP

-2шт.

32

ND949013-8220

WASHER, 0.6MM

SN: 10001-UP

-2шт.

32

ND949013-8230

WASHER, 0.9MM

SN: 10001-UP

-2шт.

33

ND949050-3390

NUT

SN: 10001-UP

1шт.

34

ND949018-1020

WASHER, 1.0MM

SN: 10001-UP

2шт.

35

ND949140-5740

O-RING

SN: 10001-UP

1шт.
