Артикул
Название
Примечание
Количество
|$1
6222-71-1120
INJECTION PUMP A.
SN: 10001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2A4 TO A4010-F2A4.
-1шт.
|$4
ND090100-8380
BODY ASS'Y
SN: 10001-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2A4 AND A4010-C2A4.
-1шт.
1
ND090110-4350
HOUSING
SN: 10001-UP
1шт.
2
ND949043-0010
STUD
SN: 10001-UP
3шт.
3
ND090206-0070
O-RING
SN: 10001-UP
1шт.
4
ND090191-1240
CAMSHAFT
SN: 10001-UP
1шт.
6
ND090193-0050
RING,ADJUST
SN: 10001-UP
1шт.
7
ND090194-0070
PLATE, 0.1MM
SN: 10001-UP
-2шт.
7
ND090194-0080
PLATE, 0.15MM
SN: 10001-UP
-2шт.
7
ND090194-0090
PLATE, 0.3MM
SN: 10001-UP
-2шт.
7
ND090194-0100
PLATE, 0.5MM
SN: 10001-UP
-2шт.
7
ND090194-0340
PLATE, 0.12MM
SN: 10001-UP
-2шт.
7
ND090194-0350
PLATE, 0.14MM
SN: 10001-UP
-2шт.
7
ND090194-0360
PLATE, 0.18MM
SN: 10001-UP
-2шт.
9
ND090201-0501
COVER,BEARING
SN: 10001-UP
1шт.
10
ND91418-06210
BOLT
SN: 10001-UP
4шт.
12
ND090361-0180
BEARING,CENTER
SN: 10001-UP
1шт.
13
ND090248-0010
WASHER
SN: 10001-UP
3шт.
14
ND090215-0060
SCREW
SN: 10001-UP
1шт.
15
ND090317-0140
PLUG,SCREW
SN: 10001-UP
1шт.
16
ND090193-0060
RING,ADJUST
SN: 10001-UP
1шт.
20
ND090244-0160
SCREW
SN: 10001-UP
2шт.
22
ND090194-0300
PLATE, 0.1MM
SN: 10001-UP
-2шт.
22
ND090194-0370
PLATE, 0.12MM
SN: 10001-UP
-2шт.
22
ND090194-0380
PLATE, 0.14MM
SN: 10001-UP
-2шт.
22
ND090194-0310
PLATE, 0.16MM
SN: 10001-UP
-2шт.
22
ND090194-0320
PLATE, 0.3MM
SN: 10001-UP
-2шт.
22
ND090194-0330
PLATE, 0.5MM
SN: 10001-UP
-2шт.
24
ND949050-3400
NUT
SN: 10001-UP
1шт.
25
ND949015-0730
WASHER,SPRING
SN: 10001-UP
1шт.
26
ND90458-05750
KEY
SN: 10001-UP
1шт.
28
ND090310-0080
VALVE ASS'Y,OVER FLOW
SN: 10001-UP
1шт.
29
ND949140-3690
O-RING
SN: 10001-UP
1шт.
Выбрано товаров: 45
