Артикул
Название
Примечание
Количество
|1
6215-71-1133
INJECTION PUMP A.,L.H.
SN: 10449-UP
1шт.
|1
0
INJECTION PUMP A.,L.H.
SN: 10304-10448
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B7A6¤C7A6B¤D7A6B¤ E7A6B¤F7A6 AND FIG.A4010-G7A6.
-1шт.
|1
0
INJECTION PUMP A.,L.H.
SN: 10001-10303
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6¤C7A6A¤D7A6A¤ E7A6A¤F7A6 AND FIG.A4010-G7A6.
-1шт.
|1
0
INJECTION PUMP A.,L.H.
SN: (10001-10046)
1шт.
|$$7
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 TO A4010-G7A6.
-1шт.
|$$8
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK106068-2062
PUMP ASS'Y
SN: 10304-UP
1шт.
|$$10
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 AND A4010- C7A6B.
-1шт.
|1
DK106068-2061
PUMP ASS'Y
SN: 10047-10303
1шт.
|$$12
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 AND A4010- C7A6A.
-1шт.
|1
DK106068-2060
PUMP ASS'Y
SN: 10001-10046
1шт.
|$$14
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 AND A4010-C7A6.
-1шт.
1
DK134070-0420
HOUSING
SN: 10001-UP
1шт.
4
DK134138-0100
STUD
SN: 10001-UP
12шт.
8
DK134340-0100
CAMSHAFT
SN: 10001-UP
1шт.
9
DK134306-1000
BEARING,CENTER
SN: 10001-UP
1шт.
10
DK020106-2040
BOLT
SN: 10001-UP
2шт.
12
DK020106-2040
BOLT
SN: 10001-UP
4шт.
19
DK134045-0100
PLUG
SN: 10001-UP
1шт.
21
DK139206-0400
NUT
SN: 10001-UP
3шт.
23
DK134047-0000
PLUG
SN: 10001-UP
6шт.
25
DK014112-0440
WASHER,SPRING
SN: 10001-UP
1шт.
26
DK023012-0040
NUT
SN: 10001-UP
1шт.
27
DK156637-5900
COUPLING
SN: 10001-UP
1шт.
30
DK131424-7120
VALVE,OVER FLOW
SN: 10001-UP
1шт.
Выбрано товаров: 53
