|1
6207-71-1510
INJECTION PUMP ASS'Y
SN: 110799-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0D6 TO A4010-F0D6.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105400-8060
GOVERNOR ASS'Y
SN: 110799-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D0D6 AND A4010-E0D6.
-1шт.
1
DK154011-0100
NUT,LOCK
SN: 110799-UP
1шт.
2
DK154500-1020
COVER
SN: 110799-UP
1шт.
3
DK154321-0400
BUSHING
SN: 110799-UP
1шт.
4
DK154031-3000
SCREW
SN: 110799-UP
1шт.
5
DK139206-0600
NUT
SN: 110799-UP
1шт.
6
DK154036-0300
PLUG
SN: 110799-UP
2шт.
7
DK020106-5040
BOLT
SN: 110799-UP
2шт.
8
DK154010-0100
SCREW
SN: 110799-UP
1шт.
9
DK020106-3840
BOLT
SN: 110799-UP
4шт.
10
DK154063-5100
COVER
SN: 110799-UP
1шт.
11
DK029020-6260
BOLT
SN: 110799-UP
2шт.
12
DK020006-2040
BOLT
SN: 110799-UP
1шт.
13
DK020006-1640
BOLT
SN: 110799-UP
1шт.
14
DK154150-2700
SPRING,GOVERNOR
SN: 110799-UP
1шт.
15
DK154158-0820
CAPSULE,SPRING
SN: 110799-UP
1шт.
16
DK154011-1700
NUT
SN: 110799-UP
1шт.
17
DK026512-1540
GASKET
SN: 110799-UP
2шт.
18
DK154159-1200
NUT,CAP
SN: 110799-UP
1шт.
19
DK154200-7120
LEVER,SWIVEL
SN: 110799-UP
1шт.
20
DK154204-3000
BUSHING
SN: 110799-UP
1шт.
21
DK029631-8020
O-RING
SN: 110799-UP
2шт.
22
DK016010-1640
RING,SNAP
SN: 110799-UP
2шт.
23
DK139611-0000
SEAL,OIL
SN: 110799-UP
1шт.
24
DK139411-0000
SHIM¤ 0.40MM
SN: 110799-UP
1шт.
25
DK029311-1090
SHIM¤ 0.30MM
SN: 110799-UP
-2шт.
26
DK154204-3100
BUSHING
SN: 110799-UP
1шт.
27
DK025803-1310
KEY¤ 13MM
SN: 110799-UP
1шт.
28
DK154206-2800
COLLAR
SN: 110799-UP
1шт.
29
DK154206-0200
WASHER¤ 1.0MM
SN: 110799-UP
-2шт.
30
DK154237-0100
PIN
SN: 110799-UP
1шт.
31
DK154395-0020
LEVER
SN: 110799-UP
1шт.
32
DK154366-8120
LEVER
SN: 110799-UP
1шт.
33
DK020006-1640
BOLT
SN: 110799-UP
1шт.
34
DK154317-0300
SPRING
SN: 110799-UP
1шт.
35
DK029631-0030
O-RING
SN: 110799-UP
1шт.
36
DK154322-0100
CAP
SN: 110799-UP
1шт.
37
DK154327-7600
SPRING
SN: 110799-UP
1шт.
38
DK029311-0520
SHIM¤ 0.2MM
SN: 110799-UP
-2шт.
|38
DK029311-0530
SHIM¤ 0.25MM
SN: 110799-UP
-2шт.
|38
DK029311-0540
SHIM¤ 0.3MM
SN: 110799-UP
-2шт.
|38
DK029311-0550
SHIM¤ 0.35MM
SN: 110799-UP
-2шт.
|38
DK029311-0560
SHIM¤ 0.4MM
SN: 110799-UP
-2шт.
|38
DK029311-0570
SHIM¤ 0.5MM
SN: 110799-UP
-2шт.
39
DK154390-0300
GASKET
SN: 110799-UP
1шт.
40
DK029635-2020
O-RING
SN: 110799-UP
1шт.
41
DK026506-1040
GASKET
SN: 110799-UP
2шт.
42
DK154035-1600
NUT,CAP
SN: 110799-UP
1шт.
43
DK154358-7200
BRACKET
SN: 110799-UP
1шт.
