Запчасти Komatsu S6D95L-1B1 ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

|1

6207-71-1120

INJECTION PUMP ASS'Y

SN: 59035-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK101069-9210

PUMP ASS'Y

SN: 59035-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.

-1шт.

1

DK131034-1401

PLUG

SN: 59035-UP

6шт.

2

DK131152-6820

PLUNGER ASS'Y

SN: 59035-UP

6шт.

3

DK131110-6820

VALVE,DELIVERY

SN: 59035-UP

6шт.

4

DK131112-4200

SPRING

SN: 59035-UP

6шт.

5

DK131115-1600

GASKET

SN: 59035-UP

6шт.

6

DK131116-8720

HOLDER

SN: 59035-UP

6шт.

7

DK131122-0520

PLATE ASS'Y

SN: 59035-UP

3шт.

8

DK029632-0030

O-RING

SN: 59035-UP

6шт.

9

DK131200-0220

TAPPET ASS'Y

SN: 59035-UP

6шт.

10

DK131203-0200

PIN

SN: 59035-UP

1шт.

11

DK131204-1000

ROLLER

SN: 59035-UP

1шт.

12

DK131205-0500

BUSHING

SN: 59035-UP

1шт.

13

DK131206-0200

GUIDE

SN: 59035-UP

1шт.

14

DK029311-0580

SHIM¤ 0.2MM

SN: 59035-UP

-2шт.

|14

DK029311-0590

SHIM¤ 0.25MM

SN: 59035-UP

-2шт.

|14

DK029311-0020

SHIM¤ 0.30MM

SN: 59035-UP

-2шт.

|14

DK029311-0600

SHIM¤ 0.35MM

SN: 59035-UP

-2шт.

|14

DK029311-0030

SHIM¤ 0.40MM

SN: 59035-UP

-2шт.

|14

DK029311-0610

SHIM¤ 0.45MM

SN: 59035-UP

-2шт.

|14

DK029311-0040

SHIM¤ 0.50MM

SN: 59035-UP

-2шт.

|14

DK029311-0270

SHIM¤ 0.55MM

SN: 59035-UP

-2шт.

|14

DK029311-0050

SHIM¤ 0.6MM

SN: 59035-UP

-2шт.

|14

DK029311-0280

SHIM¤ 0.65MM

SN: 59035-UP

-2шт.

|14

DK029311-0060

SHIM¤ 0.7MM

SN: 59035-UP

-2шт.

|14

DK029311-0290

SHIM¤ 0.75MM

SN: 59035-UP

-2шт.

|14

DK029311-0070

SHIM¤ 0.8MM

SN: 59035-UP

-2шт.

|14

DK029311-0310

SHIM¤ 0.85MM

SN: 59035-UP

-2шт.

|14

DK029311-0080

SHIM¤ 0.9MM

SN: 59035-UP

-2шт.

|14

DK029311-0320

SHIM¤ 0.95MM

SN: 59035-UP

-2шт.

|14

DK029311-0090

SHIM¤ 1.0MM

SN: 59035-UP

-2шт.

|14

DK029311-0330

SHIM¤ 1.05MM

SN: 59035-UP

-2шт.

|14

DK029311-0110

SHIM¤ 1.1MM

SN: 59035-UP

-2шт.

|14

DK029311-0340

SHIM¤ 1.15MM

SN: 59035-UP

-2шт.

|14

DK029311-0120

SHIM¤ 1.2MM

SN: 59035-UP

-2шт.

|14

DK029311-0350

SHIM¤ 1.25MM

SN: 59035-UP

-2шт.

|14

DK029311-0130

SHIM¤ 1.3MM

SN: 59035-UP

-2шт.

|14

DK029311-0620

SHIM¤ 1.35MM

SN: 59035-UP

-2шт.

|14

DK029311-0140

SHIM¤ 1.4MM

SN: 59035-UP

-2шт.

|14

DK029311-0630

SHIM¤ 1.45MM

SN: 59035-UP

-2шт.

|14

DK029311-0490

SHIM¤ 1.5MM

SN: 59035-UP

-2шт.

|14

DK029311-0710

SHIM¤ 1.55MM

SN: 59035-UP

-2шт.

|14

DK029311-0500

SHIM¤ 1.6MM

SN: 59035-UP

-2шт.

15

DK131215-2500

SPRING

SN: 59035-UP

6шт.

16

DK131216-0100

SEAT

SN: 59035-UP

6шт.

17

DK131217-0200

SEAT

SN: 59035-UP

6шт.

18

DK131256-0000

RACK,CONTROL

SN: 59035-UP

1шт.

19

DK131226-0300

SCREW

SN: 59035-UP

1шт.

20

DK131240-0100

PINION

SN: 59035-UP

6шт.

21

DK131241-0100

SLEEVE

SN: 59035-UP

6шт.

22

DK131242-0100

SCREW

SN: 59035-UP

6шт.
