Запчасти Komatsu S6D170-1G ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|$0

6162-73-2242

INJECTION PUMP ASS'Y

SN: 14060-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 12155-14059

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0455 TO 0484.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND190800-0922

GOVERNOR ASS'Y

SN: 14060-UP

1шт.

|$5

0

GOVERNOR ASS'Y

SN: 12299-14059

1шт.

|$6

0

GOVERNOR ASS'Y

SN: 12155-12298

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0465 AND 0466.

-1шт.

1

ND090810-0440

HOUSING SUB ASS'Y

SN: 12155-UP

1шт.

2

ND091167-0050

PLUG

SN: 12155-UP

1шт.

3

ND090970-0360

SHACKLE ASS'Y

SN: 12155-UP

1шт.

4

ND91518-06251

BOLT

SN: 12155-UP

3шт.

5

ND949100-2510

BEARING,BALL

SN: 12155-UP

1шт.

6

ND090978-0060

GEAR,GOVERNOR

SN: 12155-UP

1шт.

7

ND090835-0060

COLLAR

SN: 12155-UP

1шт.

|$15

ND090974-0080

GEAR ASS'Y

SN: 12155-UP

1шт.

8

ND090978-0070

GEAR,GOVERNOR

SN: 12155-UP

1шт.

9

ND091340-0060

BUSHING ASS'Y

SN: 12155-UP

1шт.

10

ND090976-0030

RING

SN: 12155-UP

1шт.

11

ND90557-28000

RING,SNAP

SN: 12155-UP

1шт.

12

ND091337-0110

DAMPER

SN: 12155-UP

4шт.

13

ND949015-0500

WASHER, 2.5MM,SPRING

SN: 12155-UP

2шт.

14

ND090844-0010

NUT

SN: 12155-UP

2шт.

15

ND90557-20000

RING,SNAP

SN: 12155-UP

1шт.

16

ND091051-0780

PLATE

SN: 12155-UP

1шт.

17

ND949100-3410

BEARING,BALL

SN: 12155-UP

1шт.

18

ND90567-47000

RING,SNAP

SN: 12155-UP

1шт.

19

ND090835-0070

COLLAR

SN: 12155-UP

1шт.

20

ND949130-0050

KEY,WOODRUFF

SN: 12155-UP

2шт.

21

ND090840-0391

FLYWEIGHT ASS'Y

SN: 12155-UP

1шт.

22

ND090860-0200

SLEEVE SUB ASS'Y

SN: 12155-UP

1шт.

23

ND090868-0040

PLATE

SN: 12155-UP

1шт.

24

ND90567-30000

RING,SNAP

SN: 12155-UP

1шт.

25

ND090900-0211

LEVER ASS'Y,TENSION

SN: 12155-UP

1шт.

26

ND090930-0571

LEVER ASS'Y,CONTROL

SN: 12155-UP

1шт.

27

ND091024-0031

SCREW,ADJUST

SN: 12155-UP

1шт.

28

ND949053-0051

NUT

SN: 12155-UP

1шт.

29

ND090823-0270

GASKET

SN: 12155-UP

1шт.

30

ND949013-4090

WASHER, 0.1MM

SN: 12155-UP

-2шт.

30

ND949013-4060

WASHER, 0.2MM

SN: 12155-UP

-2шт.

30

ND949013-4070

WASHER, 0.3MM

SN: 12155-UP

-2шт.

30

ND949013-4080

WASHER, 0.4MM

SN: 12155-UP

-2шт.

30

ND949013-4100

WASHER, 1.0MM

SN: 12155-UP

-2шт.

31

ND090894-0010

E-RING

SN: 12155-UP

1шт.

|$44

ND090910-1820

ADAPTER ASS'Y

SN: 12155-UP

1шт.

32

ND090919-0550

ADAPTER

SN: 12155-UP

1шт.

33

ND090918-2180

SPRING

SN: 12155-UP

1шт.

34

ND949013-3890

WASHER, 0.1MM

SN: 12155-UP

-2шт.

34

ND949013-4110

WASHER, 0.2MM

SN: 12155-UP

-2шт.

35

ND949013-4450

WASHER, 0.1MM

SN: 12155-UP

-2шт.

35

ND949013-3750

WASHER, 0.3MM

SN: 12155-UP

-2шт.

36

ND090911-0020

SCREW

SN: 12155-UP

1шт.

37

ND090918-1991

SPRING

SN: 12155-UP

1шт.

38

ND090923-0011

NUT,LOCK

SN: 12155-UP

1шт.

39

ND090119-0060

GASKET

SN: 12155-UP

1шт.

40

ND949013-5890

WASHER, 1.0MM

SN: 12155-UP

-2шт.

40

ND949011-3240

WASHER, 1.2MM

SN: 12155-UP

-2шт.

40

ND949011-3250

WASHER, 1.4MM

SN: 12155-UP

-2шт.

40

ND949011-3260

WASHER, 1.6MM

SN: 12155-UP

-2шт.

40

ND949011-3270

WASHER, 1.8MM

SN: 12155-UP

-2шт.

40

ND949011-3280

WASHER, 2.0MM

SN: 12155-UP

-2шт.

41

ND949044-2170

BOLT

SN: 12155-UP

8шт.

42

ND949013-6520

WASHER, 1.0MM

SN: 12155-UP

8шт.
