Запчасти Komatsu S6D170-1G ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

|$0

6162-73-2242

INJECTION PUMP ASS'Y

SN: 14060-UP

1шт.

|$1

0

INJECTION PUMP ASS'Y

SN: 12155-14059

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0455 TO 0484.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$4

ND090100-7460

BODY ASS'Y

SN: 12155-UP

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 AND 0456.

-1шт.

1

ND090110-4040

HOUSING

SN: 12155-UP

1шт.

2

ND949043-0010

STUD

SN: 12155-UP

3шт.

3

ND090191-1140

CAMSHAFT

SN: 12155-UP

1шт.

4

ND090361-0140

BEARING,CENTER

SN: 12155-UP

1шт.

5

ND90015-06181

SCREW

SN: 12155-UP

2шт.

6

ND949101-0130

BEARING,ROLLER

SN: 12155-UP

1шт.

7

ND090201-0620

COVER,BEARING

SN: 12155-UP

1шт.

8

ND949150-2290

SEAL,OIL

SN: 12155-UP

1шт.

9

ND090139-0060

O-RING

SN: 12155-UP

1шт.

10

ND090208-0150

SHIM, 0.03MM

SN: 12155-UP

-2шт.

10

ND090208-0160

SHIM, 0.05MM

SN: 12155-UP

-2шт.

10

ND090208-0170

SHIM, 0.07MM

SN: 12155-UP

-2шт.

10

ND090208-0180

SHIM, 0.1MM

SN: 12155-UP

-2шт.

10

ND090208-0190

SHIM, 0.2MM

SN: 12155-UP

-2шт.

10

ND090208-0200

SHIM, 0.3MM

SN: 12155-UP

-2шт.

10

ND090208-0210

SHIM, 0.5MM

SN: 12155-UP

-2шт.

11

ND090433-0010

RETAINER,BEARING

SN: 12155-UP

1шт.

12

ND090317-0070

PLUG

SN: 12155-UP

1шт.

13

ND090317-0060

PLUG

SN: 12155-UP

6шт.

14

ND949101-0170

BEARING,ROLLER

SN: 12155-UP

1шт.

15

ND949180-0310

SCREW

SN: 12155-UP

2шт.

16

ND090310-0290

VALVE ASS'Y,OVER FLOW

SN: 12155-UP

1шт.

17

ND090222-0070

WASHER

SN: 12155-UP

6шт.

18

ND949018-1210

WASHER

SN: 12155-UP

1шт.

19

ND949047-1790

BOLT

SN: 12155-UP

2шт.

20

ND090106-0040

GASKET

SN: 12155-UP

1шт.

21

ND949018-0710

WASHER, 2MM

SN: 12155-UP

1шт.

22

ND949018-1500

WASHER, 1MM

SN: 12155-UP

6шт.

23

ND090118-0270

NEEDLE,TIMING

SN: 12155-UP

1шт.

24

ND090012-0310

NUT

SN: 12155-UP

1шт.

25

ND949014-0320

WASHER,SPRING

SN: 12155-UP

1шт.

26

ND90458-05750

KEY,WOODRUFF

SN: 12155-UP

1шт.
