Запчасти Komatsu S6D170-1G-R ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

|1

6162-73-1781

INJECTION PUMP ASS'Y

SN: .-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 12952-.

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0457 TO 0485.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK106069-8110

PUMP ASS'Y

SN: 12952-UP

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0457 AND 0458.

-1шт.

1

DK134145-1120

PLUNGER ASS'Y

SN: 12952-UP

6шт.

2

DK029331-9040

GASKET

SN: 12952-UP

1шт.

3

DK134151-2720

PLUNGER ASS'Y

SN: 12952-UP

1шт.

4

DK134563-0600

PIN

SN: 12952-UP

1шт.

5

DK134110-6220

VALVE,DELIVERY

SN: 12952-UP

1шт.

6

DK134116-3020

HOLDER

SN: 12952-UP

1шт.

7

DK029632-5080

O-RING

SN: 12952-UP

1шт.

8

DK134117-0500

STOPPER

SN: 12952-UP

1шт.

9

DK134112-2000

SPRING

SN: 12952-UP

1шт.

10

DK134115-0100

GASKET

SN: 12952-UP

1шт.

11

DK029632-9040

O-RING

SN: 12952-UP

2шт.

12

DK134139-2400

SHIM¤ 0.15MM

SN: 12952-UP

-2шт.

|12

DK134139-2500

SHIM¤ 0.40MM

SN: 12952-UP

-2шт.

|12

DK134139-2600

SHIM¤ 0.50MM

SN: 12952-UP

-2шт.

|12

DK134139-2700

SHIM¤ 0.60MM

SN: 12952-UP

-2шт.

|12

DK134139-2800

SHIM¤ 0.70MM

SN: 12952-UP

-2шт.

|12

DK134139-2900

SHIM¤ 0.80MM

SN: 12952-UP

-2шт.

|12

DK134139-3000

SHIM¤ 0.90MM

SN: 12952-UP

-2шт.

|12

DK134139-3100

SHIM¤ 1.00MM

SN: 12952-UP

-2шт.

13

DK029301-2330

WASHER

SN: 12952-UP

12шт.

14

DK014111-2440

WASHER,SPRING

SN: 12952-UP

12шт.

15

DK013021-2140

NUT

SN: 12952-UP

12шт.

16

DK134256-2000

RACK,CONTROL

SN: 12952-UP

1шт.

17

DK134222-0100

BUSHING

SN: 12952-UP

1шт.

18

DK134215-0100

SPRING,PLUNGER

SN: 12952-UP

6шт.

19

DK134217-0200

SEAT,SPRING

SN: 12952-UP

6шт.

20

DK134200-0520

TAPPET

SN: 12952-UP

6шт.

21

DK134140-0400

SEAT¤ 3.90MM

SN: 12952-UP

6шт.

22

DK134416-1500

COVER

SN: 12952-UP

1шт.

23

DK014530-6540

WASHER,LOCK

SN: 12952-UP

2шт.

24

DK021306-3940

SCREW

SN: 12952-UP

2шт.
