Запчасти Komatsu S6D140-1R ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС)(№-) ТОПЛИВН. СИСТЕМА

|1

6211-71-1314

INJECTION PUMP A.

SN: 15600-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451C TO 0481C.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105217-1480

FEED PUMP ASS'Y

SN: 15600-UP

1шт.

1

DK152004-1620

HOUSING

SN: 15600-UP

1шт.

2

DK152100-1120

PISTON

SN: 15600-UP

1шт.

3

DK152102-1600

SPRING,PISTON

SN: 15600-UP

1шт.

4

DK152105-0200

PLUG

SN: 15600-UP

1шт.

5

DK029332-6030

GASKET

SN: 15600-UP

1шт.

6

DK152111-4020

TAPPET

SN: 15600-UP

1шт.

7

DK152115-0500

VALVE

SN: 15600-UP

2шт.

8

DK152116-0200

SPRING

SN: 15600-UP

2шт.

9

DK152117-0400

PLUG

SN: 15600-UP

1шт.

10

DK029631-6060

O-RING

SN: 15600-UP

1шт.

11

DK029331-6030

GASKET

SN: 15600-UP

1шт.

12

DK152121-0200

RING,SNAP

SN: 15600-UP

1шт.

13

DK152200-5320

PUMP,PRIMING

SN: 15600-UP

1шт.

14

DK152300-5920

BOLT,JOINT

SN: 15600-UP

1шт.

15

DK029731-4680

BOLT,JOINT

SN: 15600-UP

1шт.

16

DK029711-4310

EYE,EYE

SN: 15600-UP

1шт.

17

DK029341-4130

GASKET

SN: 15600-UP

2шт.

18

DK029341-4130

GASKET

SN: 15600-UP

2шт.

19

DK152320-0100

COVER

SN: 15600-UP

1шт.
