Запчасти Komatsu S6D140-1R ТОПЛ. НАСОС (СОЕДИНЕНИЕ)(№-) ТОПЛИВН. СИСТЕМА

|$0

6211-71-1314

INJECTION PUMP A.

SN: 15600-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451C TO 0481C.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105663-0380

COUPLING ASS'Y

SN: 15600-UP

1шт.

1

DK156630-6600

COUPLING

SN: 15600-UP

1шт.

2

DK156633-8200

BOLT

SN: 15600-UP

2шт.

3

DK156615-2800

WASHER

SN: 15600-UP

2шт.

4

DK156605-5320

PLATE

SN: 15600-UP

2шт.

5

DK156617-2100

NUT

SN: 15600-UP

2шт.

6

DK156633-3300

BOLT

SN: 15600-UP

4шт.

7

DK156609-6300

COUPLING,CROSS

SN: 15600-UP

1шт.

8

DK156633-8300

BOLT

SN: 15600-UP

2шт.

9

DK156633-8400

BOLT

SN: 15600-UP

1шт.

|$0

6211-71-1314

INJECTION PUMP A.

SN: 15600-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451C TO 0481C.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105663-0380

COUPLING ASS'Y

SN: 15600-UP

1шт.

1

DK156630-6600

COUPLING

SN: 15600-UP

1шт.

2

DK156633-8200

BOLT

SN: 15600-UP

2шт.

3

DK156615-2800

WASHER

SN: 15600-UP

2шт.

4

DK156605-5320

PLATE

SN: 15600-UP

2шт.

5

DK156617-2100

NUT

SN: 15600-UP

2шт.

6

DK156633-3300

BOLT

SN: 15600-UP

4шт.

7

DK156609-6300

COUPLING,CROSS

SN: 15600-UP

1шт.

8

DK156633-8300

BOLT

SN: 15600-UP

2шт.

9

DK156633-8400

BOLT

SN: 15600-UP

1шт.
