Артикул
Название
Примечание
Количество
|$0
6151-71-1450
INJECTION PUMP A.
SN: 38630-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A,0451B,0461A,0462A, 0471A TO 0481A.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105407-3702
GOVERNOR ASS'Y
SN: 38630-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.
-1шт.
1
DK154000-5720
HOUSING
SN: 38630-UP
1шт.
3
DK154007-2900
PLUG
SN: 38630-UP
1шт.
4
DK154350-6000
PLATE
SN: 38630-UP
1шт.
5
DK020106-2040
BOLT
SN: 38630-UP
8шт.
6
DK154010-1100
SCREW
SN: 38630-UP
1шт.
10
DK155404-1700
CAP
SN: 38630-UP
1шт.
12
DK154101-0020
FLYWEIGHT ASS'Y
SN: 38630-UP
1шт.
13
DK025803-1610
KEY, 16MM
SN: 38630-UP
1шт.
15
DK029231-2030
NUT
SN: 38630-UP
1шт.
17
DK029311-0180
SHIM, 0.30MM
SN: 38630-UP
-2шт.
17
DK139410-0000
SHIM, 0.50MM
SN: 38630-UP
-2шт.
17
DK029311-0210
SHIM, 1.00MM
SN: 38630-UP
-2шт.
17
DK139410-0100
SHIM, 1.50MM
SN: 38630-UP
-2шт.
17
DK139410-3100
SHIM, 3.00MM
SN: 38630-UP
-2шт.
17
DK139410-3200
SHIM, 4.00MM
SN: 38630-UP
-2шт.
19
DK154177-2420
CAPSULE,SPRING
SN: 38630-UP
1шт.
20
DK029201-6010
NUT
SN: 38630-UP
1шт.
22
DK154230-2920
LINK
SN: 38630-UP
1шт.
23
DK016010-0540
RING,SNAP
SN: 38630-UP
1шт.
25
DK154326-5020
LEVER ASS'Y
SN: 38630-UP
1шт.
27
DK155412-5300
IMPELLER
SN: 38630-UP
1шт.
|$0
6151-71-1450
INJECTION PUMP A.
SN: 38630-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A,0451B,0461A,0462A, 0471A TO 0481A.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105407-3702
GOVERNOR ASS'Y
SN: 38630-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.
-1шт.
1
DK154000-5720
HOUSING
SN: 38630-UP
1шт.
3
DK154007-2900
PLUG
SN: 38630-UP
1шт.
4
DK154350-6000
PLATE
SN: 38630-UP
1шт.
5
DK020106-2040
BOLT
SN: 38630-UP
8шт.
6
DK154010-1100
SCREW
SN: 38630-UP
1шт.
10
DK155404-1700
CAP
SN: 38630-UP
1шт.
12
DK154101-0020
FLYWEIGHT ASS'Y
SN: 38630-UP
1шт.
13
DK025803-1610
KEY, 16MM
SN: 38630-UP
1шт.
15
DK029231-2030
NUT
SN: 38630-UP
1шт.
17
DK029311-0180
SHIM, 0.30MM
SN: 38630-UP
-2шт.
17
DK139410-0000
SHIM, 0.50MM
SN: 38630-UP
-2шт.
17
DK029311-0210
SHIM, 1.00MM
SN: 38630-UP
-2шт.
17
DK139410-0100
SHIM, 1.50MM
SN: 38630-UP
-2шт.
17
DK139410-3100
SHIM, 3.00MM
SN: 38630-UP
-2шт.
17
DK139410-3200
SHIM, 4.00MM
SN: 38630-UP
-2шт.
19
DK154177-2420
CAPSULE,SPRING
SN: 38630-UP
1шт.
20
DK029201-6010
NUT
SN: 38630-UP
1шт.
22
DK154230-2920
LINK
SN: 38630-UP
1шт.
23
DK016010-0540
RING,SNAP
SN: 38630-UP
1шт.
25
DK154326-5020
LEVER ASS'Y
SN: 38630-UP
1шт.
27
DK155412-5300
IMPELLER
SN: 38630-UP
1шт.
Выбрано товаров: 80
