Артикул
Название
Примечание
Количество
|1
6151-73-1220
INJECTION PUMP A.
SN: 35323-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452¤0463¤0464¤0472 AND 0482.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-6710
BODY ASS'Y
SN: 35323-UP
1шт.
1
ND090110-3741
HOUSING,PUMP
SN: 35323-UP
1шт.
2
ND949043-0010
STUD
SN: 35323-UP
3шт.
3
ND090130-0290
HOLDER,DELIVERY VALVE
SN: 35323-UP
6шт.
4
ND090136-0770
SPRING,DELIVERY
SN: 35323-UP
6шт.
7
ND090150-3250
ELEMENT,PUMP
SN: 35323-UP
6шт.
8
ND090160-0060
SLEEVE,CONTROL
SN: 35323-UP
6шт.
9
ND090212-0471
RACK,CONTROL
SN: 35323-UP
1шт.
10
ND090163-0131
SEAT,UPPER
SN: 35323-UP
6шт.
11
ND090164-0250
SPRING,PLUNGER
SN: 35323-UP
6шт.
12
ND090165-0150
SEAT,LOWER
SN: 35323-UP
6шт.
13
ND090170-0230
TAPPET ASS'Y
SN: 35323-UP
6шт.
14
ND090438-0390
SHIM¤ 1.75MM
SN: 35323-UP
-2шт.
|14
ND090438-0400
SHIM¤ 1.8MM
SN: 35323-UP
-2шт.
|14
ND090438-0410
SHIM¤ 1.85MM
SN: 35323-UP
-2шт.
|14
ND090438-0420
SHIM¤ 1.9MM
SN: 35323-UP
-2шт.
|14
ND090438-0430
SHIM¤ 1.95MM
SN: 35323-UP
-2шт.
|14
ND090438-0440
SHIM¤ 2.0MM
SN: 35323-UP
-2шт.
|14
ND090438-0450
SHIM¤ 2.05MM
SN: 35323-UP
-2шт.
|14
ND090438-0460
SHIM¤ 2.1MM
SN: 35323-UP
-2шт.
|14
ND090438-0470
SHIM¤ 2.15MM
SN: 35323-UP
-2шт.
|14
ND090438-0480
SHIM¤ 2.2MM
SN: 35323-UP
-2шт.
|14
ND090438-0490
SHIM¤ 2.25MM
SN: 35323-UP
-2шт.
|14
ND090438-0500
SHIM¤ 2.3MM
SN: 35323-UP
-2шт.
|14
ND090438-0510
SHIM¤ 2.35MM
SN: 35323-UP
-2шт.
|14
ND090438-0520
SHIM¤ 2.4MM
SN: 35323-UP
-2шт.
21
ND090193-0050
RING,ADJUST
SN: 35323-UP
1шт.
22
ND090194-0070
PLATE¤ 0.1MM
SN: 35323-UP
-2шт.
|22
ND090194-0080
PLATE¤ 0.15MM
SN: 35323-UP
-2шт.
|22
ND090194-0090
PLATE¤ 0.3MM
SN: 35323-UP
-2шт.
|22
ND090194-0100
PLATE¤ 0.5MM
SN: 35323-UP
-2шт.
24
ND090201-0430
COVER,BEARING
SN: 35323-UP
1шт.
25
ND949047-1380
BOLT
SN: 35323-UP
4шт.
28
ND090248-0010
WASHER
SN: 35323-UP
2шт.
29
ND090215-0011
SCREW,GUIDE
SN: 35323-UP
1шт.
30
ND090317-0140
PLUG
SN: 35323-UP
1шт.
31
ND090193-0060
RING,ADJUST
SN: 35323-UP
1шт.
32
ND090118-0250
NEEDLE,TIMING
SN: 35323-UP
1шт.
37
ND090194-0300
PLATE¤ 0.1MM
SN: 35323-UP
-2шт.
|37
ND090194-0310
PLATE¤ 0.16MM
SN: 35323-UP
-2шт.
|37
ND090194-0320
PLATE¤ 0.3MM
SN: 35323-UP
-2шт.
|37
ND090194-0330
PLATE¤ 0.5MM
SN: 35323-UP
-2шт.
38
ND949047-0620
BOLT
SN: 35323-UP
2шт.
40
ND090367-0040
BUSHING,CONTROL
SN: 35323-UP
1шт.
42
ND090018-0410
COVER,CONTROL RACK
SN: 35323-UP
1шт.
43
ND090012-0140
NUT,ROUND
SN: 35323-UP
1шт.
44
ND949014-0070
WASHER,SPRING
SN: 35323-UP
1шт.
47
ND090310-0080
VALVE ASS'Y,OVER FLOW
SN: 35323-UP
1шт.
48
ND90458-05750
KEY,WOODRUFF
SN: 35323-UP
1шт.
Выбрано товаров: 71
