Артикул
Название
Примечание
Количество
|1
6151-71-1116
INJECTION PUMP A.
SN: 35042-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 26688-35041
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452 TO 0482.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
DK152004-1620
HOUSING
SN: 26688-UP
1шт.
2
DK152100-1120
PISTON
SN: 26688-UP
1шт.
4
DK152105-1500
PLUG
SN: 26688-UP
1шт.
5
DK029332-6030
GASKET
SN: 26688-UP
1шт.
6
DK152111-4020
TAPPET
SN: 26688-UP
1шт.
7
DK152115-0500
VALVE
SN: 26688-UP
2шт.
9
DK152117-0400
PLUG
SN: 26688-UP
1шт.
12
DK152121-0200
RING,SNAP
SN: 26688-UP
1шт.
14
DK152300-5920
BOLT,JOINT
SN: 26688-UP
1шт.
15
DK029731-4680
BOLT,JOINT
SN: 26688-UP
1шт.
16
DK029711-4310
EYE
SN: 26688-UP
1шт.
|1
6151-71-1116
INJECTION PUMP A.
SN: 35042-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 26688-35041
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452 TO 0482.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
DK152004-1620
HOUSING
SN: 26688-UP
1шт.
2
DK152100-1120
PISTON
SN: 26688-UP
1шт.
4
DK152105-1500
PLUG
SN: 26688-UP
1шт.
5
DK029332-6030
GASKET
SN: 26688-UP
1шт.
6
DK152111-4020
TAPPET
SN: 26688-UP
1шт.
7
DK152115-0500
VALVE
SN: 26688-UP
2шт.
9
DK152117-0400
PLUG
SN: 26688-UP
1шт.
12
DK152121-0200
RING,SNAP
SN: 26688-UP
1шт.
14
DK152300-5920
BOLT,JOINT
SN: 26688-UP
1шт.
15
DK029731-4680
BOLT,JOINT
SN: 26688-UP
1шт.
16
DK029711-4310
EYE
SN: 26688-UP
1шт.
Выбрано товаров: 48
