Запчасти Komatsu S6D125-1AD ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)(№97-) ТОПЛИВН. СИСТЕМА

|1

6151-71-1552

INJECTION PUMP ASS'Y

SN: 56973-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.

-1шт.

|1

ND190800-4110

GOVERNOR ASS'Y

SN: 56973-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.

-1шт.

1

ND090810-0540

HOUSING

SN: 56973-UP

1шт.

2

ND090878-0260

PLATE

SN: 56973-UP

1шт.

3

ND091024-0031

SCREW,ADJUST

SN: 56973-UP

1шт.

4

ND090901-0150

LEVER ASS'Y,TENSION

SN: 56973-UP

1шт.

5

ND090930-0490

LEVER ASS'Y,CONTROL

SN: 56973-UP

1шт.

6

ND090894-0010

E-RING

SN: 56973-UP

1шт.

7

ND948053-0051

NUT

SN: 56973-UP

1шт.

8

ND091046-0010

SLIDER,SUPPORT

SN: 56973-UP

1шт.

9

ND090970-0350

SHACKLE ASS'Y

SN: 56973-UP

1шт.

10

ND949130-0050

KEY

SN: 56973-UP

1шт.

11

ND090840-0520

FLYWEIGHT ASS'Y

SN: 56973-UP

1шт.

12

ND949015-0500

WASHER¤ 2.5MM,SPRING

SN: 56973-UP

1шт.

13

ND090844-0010

NUT

SN: 56973-UP

1шт.

14

ND090860-0200

SLEEVE SUB ASS'Y

SN: 56973-UP

1шт.

15

ND090868-0040

PLATE,THRUST

SN: 56973-UP

1шт.

16

ND90567-30000

RING,SNAP

SN: 56973-UP

1шт.

17

ND949013-4090

WASHER¤ 0.1MM

SN: 56973-UP

-2шт.

|17

ND949013-4060

WASHER¤ 0.2MM

SN: 56973-UP

-2шт.

|17

ND949013-4070

WASHER¤ 0.3MM

SN: 56973-UP

-2шт.

|17

ND949013-4080

WASHER¤ 0.4MM

SN: 56973-UP

-2шт.

|17

ND949013-4100

WASHER¤ 1.0MM

SN: 56973-UP

-2шт.

18

ND090992-0410

SPRING,CONTROL

SN: 56973-UP

1шт.

19

ND090993-0280

SPRING,START

SN: 56973-UP

1шт.

|20

ND090910-0430

ADAPTER ASS'Y

SN: 56973-UP

1шт.

20

ND090911-0010

SCREW

SN: 56973-UP

1шт.

21

ND090894-0010

E-RING

SN: 56973-UP

1шт.

22

ND090918-0380

SPRING,GOVERNOR

SN: 56973-UP

1шт.

23

ND090919-0010

ADAPTER

SN: 56973-UP

1шт.

24

ND090921-0010

WASHER,GOVERNOR

SN: 56973-UP

1шт.

25

ND949013-3880

WASHER¤ 0.1MM

SN: 56973-UP

-2шт.

|25

ND949013-4040

WASHER¤ 0.2MM

SN: 56973-UP

-2шт.

|25

ND949013-4020

WASHER¤ 0.25MM

SN: 56973-UP

-2шт.

|25

ND949013-4030

WASHER¤ 0.5MM

SN: 56973-UP

-2шт.

|25

ND949013-7880

WASHER¤ 1.0MM

SN: 56973-UP

-2шт.

26

ND090923-0011

NUT,LOCK

SN: 56973-UP

1шт.

27

ND090224-0140

PLUG

SN: 56973-UP

1шт.

28

ND090119-0160

GASKET

SN: 56973-UP

1шт.

29

ND090823-0420

GASKET

SN: 56973-UP

1шт.

30

ND090245-0230

SCREW

SN: 56973-UP

1шт.

31

ND090222-0120

WASHER

SN: 56973-UP

2шт.

32

ND949018-1550

WASHER

SN: 56973-UP

1шт.

33

ND949047-6880

BOLT

SN: 56973-UP

2шт.

34

ND949047-6900

BOLT

SN: 56973-UP

1шт.

35

ND949047-6890

BOLT

SN: 56973-UP

4шт.

36

ND949047-6910

BOLT

SN: 56973-UP

1шт.
