Запчасти Komatsu S6D110-1G ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|1

6138-72-1153

INJECTION PUMP ASS'Y

SN: 56692-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0454¤0455¤0463A¤0464A¤0472 AND 0482.

-1шт.

|1

0

INJECTION PUMP ASS'Y

SN: (56692-63091)

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452¤0463¤0464¤0472 AND 0482.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105662-0870

COUPLING ASS'Y

SN: 56692-UP

1шт.

1

DK156630-0700

COUPLING

SN: 56692-UP

1шт.

2

DK156633-6200

BOLT

SN: 56692-UP

2шт.

3

DK156615-3300

WASHER

SN: 56692-UP

2шт.

4

DK156605-2320

PLATE

SN: 56692-UP

2шт.

5

DK029200-8050

NUT

SN: 56692-UP

2шт.

6

DK156633-6200

BOLT

SN: 56692-UP

4шт.

7

DK156609-7500

COUPLING,CROSS

SN: 56692-UP

1шт.

8

DK156633-6300

BOLT

SN: 56692-UP

2шт.

9

DK156633-1200

BOLT

SN: 56692-UP

1шт.

|1

6138-72-1153

INJECTION PUMP ASS'Y

SN: 56692-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0454¤0455¤0463A¤0464A¤0472 AND 0482.

-1шт.

|1

0

INJECTION PUMP ASS'Y

SN: (56692-63091)

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452¤0463¤0464¤0472 AND 0482.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105662-0870

COUPLING ASS'Y

SN: 56692-UP

1шт.

1

DK156630-0700

COUPLING

SN: 56692-UP

1шт.

2

DK156633-6200

BOLT

SN: 56692-UP

2шт.

3

DK156615-3300

WASHER

SN: 56692-UP

2шт.

4

DK156605-2320

PLATE

SN: 56692-UP

2шт.

5

DK029200-8050

NUT

SN: 56692-UP

2шт.

6

DK156633-6200

BOLT

SN: 56692-UP

4шт.

7

DK156609-7500

COUPLING,CROSS

SN: 56692-UP

1шт.

8

DK156633-6300

BOLT

SN: 56692-UP

2шт.

9

DK156633-1200

BOLT

SN: 56692-UP

1шт.
