Запчасти Komatsu S6D110-1A ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (КРОМЕ ЯПОН.) (МОРОЗОУСТОЙЧИВ. СПЕЦИФИКАЦИЯ.) ТОПЛИВН. СИСТЕМА

|$0

6138-72-1160

INJECTION PUMP ASS'Y

SN: 50195-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453,0465,0466,0473,0483 AND 0493.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105410-7831

GOVERNOR ASS'Y

SN: 50195-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0465 AND 0466.

-1шт.

1

DK154000-6400

HOUSING

SN: 50195-UP

1шт.

2

DK029632-5070

O-RING

SN: 50195-UP

1шт.

3

DK154007-2900

PLUG

SN: 50195-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 50195-UP

1шт.

5

DK020018-1840

BOLT

SN: 50195-UP

1шт.

6

DK154350-1900

PLATE

SN: 50195-UP

1шт.

7

DK020006-1440

BOLT

SN: 50195-UP

6шт.

8

DK154010-0100

SCREW

SN: 50195-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 50195-UP

1шт.

10

DK154012-2220

BOLT

SN: 50195-UP

1шт.

11

DK014110-8440

WASHER,SPRING

SN: 50195-UP

1шт.

12

DK155404-5700

CAP

SN: 50195-UP

1шт.

13

DK154101-0520

FLYWEIGHT ASS'Y

SN: 50195-UP

1шт.

14

DK025803-1610

KEY, 16MM,WOODRUFF

SN: 50195-UP

1шт.

15

DK029321-2020

WASHER,SPRING

SN: 50195-UP

1шт.

16

DK029231-2030

NUT

SN: 50195-UP

1шт.

17

DK154123-0120

SLEEVE

SN: 50195-UP

1шт.

18

DK029801-0030

BEARING

SN: 50195-UP

1шт.

19

DK029311-0010

SHIM, 0.20MM

SN: 50195-UP

-2шт.

19

DK029311-0180

SHIM, 0.30MM

SN: 50195-UP

-2шт.

19

DK029311-0190

SHIM, 0.40MM

SN: 50195-UP

-2шт.

19

DK139410-0000

SHIM, 0.50MM

SN: 50195-UP

-2шт.

19

DK029311-0210

SHIM, 1.00MM

SN: 50195-UP

-2шт.

19

DK139410-0100

SHIM, 1.50MM

SN: 50195-UP

-2шт.

20

DK154154-0701

SPRING

SN: 50195-UP

1шт.

21

DK154185-3620

CAPSULE,SPRING

SN: 50195-UP

1шт.

22

DK029201-6080

NUT

SN: 50195-UP

1шт.

23

DK154210-7420

GUIDE LEVER ASS'Y

SN: 50195-UP

1шт.

24

DK154230-0120

LINK

SN: 50195-UP

1шт.

25

DK016010-0540

RING,SNAP

SN: 50195-UP

1шт.

26

DK154236-4100

LEVER,TENSION

SN: 50195-UP

1шт.

27

DK155412-5200

IMPELLER

SN: 50195-UP

1шт.

28

DK154350-7700

GASKET

SN: 50195-UP

1шт.

29

DK154172-4120

CAPSULE,SPRING

SN: 50195-UP

1шт.

30

DK029201-6010

NUT

SN: 50195-UP

1шт.
