Артикул
Название
Примечание
Количество
|1
6222-73-1220
INJECTION PUMP ASS'Y
SN: 15882-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2B3 TO A4010-F2B3.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105954-0160
GOVERNOR ASS'Y,MECHANICAL
SN: 15882-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D2B3 AND A4010-E2B3.
-1шт.
1
DK159560-1100
HOUSING
SN: 15882-UP
1шт.
2
DK029010-6810
BOLT
SN: 15882-UP
6шт.
3
DK020018-1840
BOLT
SN: 15882-UP
1шт.
4
DK029621-7050
SEAL,OIL
SN: 15882-UP
1шт.
5
DK159564-1200
SPRING
SN: 15882-UP
1шт.
6
DK159564-3600
SEAT,SPRING
SN: 15882-UP
1шт.
7
DK159564-1600
CONNECTOR
SN: 15882-UP
1шт.
8
DK159564-4300
BOLT
SN: 15882-UP
1шт.
9
DK159564-3700
PLATE
SN: 15882-UP
1шт.
10
DK159564-4200
BOLT
SN: 15882-UP
1шт.
11
DK154390-1300
GASKET
SN: 15882-UP
1шт.
12
DK154050-1720
LIMITER
SN: 15882-UP
1шт.
13
DK154007-0200
ADAPTER
SN: 15882-UP
1шт.
14
DK014110-5440
WASHER,SPRING
SN: 15882-UP
2шт.
15
DK159564-8600
GEAR
SN: 15882-UP
1шт.
16
DK014111-2420
WASHER,SPRING
SN: 15882-UP
1шт.
17
DK013031-2120
NUT
SN: 15882-UP
1шт.
18
DK025803-1610
KEY¤ 16MM,WOODRUFF
SN: 15882-UP
1шт.
|1
6222-73-1220
INJECTION PUMP ASS'Y
SN: 15882-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2B3 TO A4010-F2B3.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105954-0160
GOVERNOR ASS'Y,MECHANICAL
SN: 15882-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D2B3 AND A4010-E2B3.
-1шт.
1
DK159560-1100
HOUSING
SN: 15882-UP
1шт.
2
DK029010-6810
BOLT
SN: 15882-UP
6шт.
3
DK020018-1840
BOLT
SN: 15882-UP
1шт.
4
DK029621-7050
SEAL,OIL
SN: 15882-UP
1шт.
5
DK159564-1200
SPRING
SN: 15882-UP
1шт.
6
DK159564-3600
SEAT,SPRING
SN: 15882-UP
1шт.
7
DK159564-1600
CONNECTOR
SN: 15882-UP
1шт.
8
DK159564-4300
BOLT
SN: 15882-UP
1шт.
9
DK159564-3700
PLATE
SN: 15882-UP
1шт.
10
DK159564-4200
BOLT
SN: 15882-UP
1шт.
11
DK154390-1300
GASKET
SN: 15882-UP
1шт.
12
DK154050-1720
LIMITER
SN: 15882-UP
1шт.
13
DK154007-0200
ADAPTER
SN: 15882-UP
1шт.
14
DK014110-5440
WASHER,SPRING
SN: 15882-UP
2шт.
15
DK159564-8600
GEAR
SN: 15882-UP
1шт.
16
DK014111-2420
WASHER,SPRING
SN: 15882-UP
1шт.
17
DK013031-2120
NUT
SN: 15882-UP
1шт.
18
DK025803-1610
KEY¤ 16MM,WOODRUFF
SN: 15882-UP
1шт.
Выбрано товаров: 46
