Запчасти Komatsu S6D108-1C-6 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|1

6221-11-1300

CYLINDER HEAD ASS'Y

SN: 10001-UP

1шт.

1

0

HEAD,CYLINDER

SN: 10001-UP

1шт.

2

6221-19-1311

GUIDE,EXHAUST VALVE

SN: 10001-UP

6шт.

3

6221-19-1340

GUIDE,INTAKE VALVE

SN: 10001-UP

6шт.

4

6221-13-1360

SEAT,INTAKE VALVE (STD)

SN: 13936-UP

6шт.

|4

0

SEAT,INTAKE VALVE (STD)

SN: 10001-13935

6шт.

|4

6221-19-1360

SEAT¤ 0.25MM,INTAKE VALVE (OS)

SN: 13936-UP

6шт.

|4

0

SEAT¤ 0.25MM,INTAKE VALVE (OS)

SN: 10001-13935

6шт.

|4

6221-18-1360

SEAT¤ 0.50MM,INTAKE VALVE (OS)

SN: 13936-UP

6шт.

|4

0

SEAT¤ 0.50MM,INTAKE VALVE (OS)

SN: 10001-13935

6шт.

|4

6221-17-1360

SEAT¤ 0.75MM,INTAKE VALVE (OS)

SN: 13936-UP

6шт.

|4

0

SEAT¤ 0.75MM,INTAKE VALVE (OS)

SN: 10001-13935

6шт.

|4

6221-16-1360

SEAT¤ 1.00MM,INTAKE VALVE (OS)

SN: 13936-UP

6шт.

|4

0

SEAT¤ 1.00MM,INTAKE VALVE (OS)

SN: 10001-13935

6шт.

5

6221-11-1320

SEAT,EXHAUST VALVE (STD)

SN: 10001-UP

6шт.

|5

6221-19-1320

SEAT¤ 0.25MM,EXHAUST VALVE (OS)

SN: 10001-UP

6шт.

|5

6221-18-1320

SEAT¤ 0.50MM,EXHAUST VALVE (OS)

SN: 10001-UP

6шт.

|5

6221-17-1320

SEAT¤ 0.75MM,EXHAUST VALVE (OS)

SN: 10001-UP

6шт.

|5

6221-16-1320

SEAT¤ 1.00MM,EXHAUST VALVE (OS)

SN: 10001-UP

6шт.

6

07046-41810

PLUG

SN: 19685-UP

9шт.

|6

07046-41810

PLUG

SN: 10001-19684

8шт.

7

07046-42816

PLUG

SN: 10001-UP

17шт.

8

07046-44016

PLUG

SN: 10001-UP

4шт.

9

07043-70108

PLUG

SN: 10001-UP

7шт.

10

6221-41-4110

VALVE,INTAKE

SN: 10001-UP

6шт.

11

6221-41-4210

VALVE,EXHAUST

SN: 10001-UP

6шт.

12

6221-41-4510

GUIDE,SPRING

SN: 10001-UP

12шт.

13

6136-42-4520

COTTER,VALVE

SN: 10001-UP

24шт.

14

6221-41-4410

SPRING,VALVE

SN: 10001-UP

12шт.

15

6140-41-4540

SEAL,EXHAUST VALVE

SN: 10001-UP

6шт.

16

6221-17-1810

GASKET

SN: 10001-UP

1шт.

17

6221-11-1610

BOLT

SN: 10001-UP

26шт.
