Артикул
Название
Примечание
Количество
|$0
6137-72-1321
INJECTION PUMP ASS'Y
SN: 61481-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451,0461,0462,0471 AND FIGS.0481.
-1шт.
|$2
6137-72-1340
INJECTION PUMP ASS'Y,(FOR SWEDEN)
SN: 61481-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451,0463,0464,0471 AND 0481.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105661-0371
COUPLING ASS'Y
SN: 61481-UP
1шт.
1
DK156630-0500
COUPLING
SN: 61481-UP
1шт.
2
DK156605-2320
PLATE
SN: 61481-UP
2шт.
3
DK156609-5900
COUPLING,CROSS
SN: 61481-UP
1шт.
4
DK156633-6200
BOLT
SN: 61481-UP
8шт.
5
DK156615-3300
WASHER,LOCK
SN: 61481-UP
2шт.
6
DK029200-8050
NUT
SN: 61481-UP
2шт.
7
DK156633-6000
BOLT
SN: 61481-UP
1шт.
Выбрано товаров: 13
