Артикул
Название
Примечание
Количество
|$0
6137-72-1111
INJECTION PUMP ASS'Y
SN: 86535-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105411-1230
GOVERNOR ASS'Y
SN: 86535-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.
-1шт.
1
DK154004-5020
HOUSING
SN: 86535-UP
1шт.
2
DK154007-2900
PLUG
SN: 86535-UP
1шт.
3
DK154353-4600
GASKET
SN: 86535-UP
1шт.
4
DK154063-7900
COVER
SN: 86535-UP
1шт.
5
DK020006-1640
BOLT
SN: 86535-UP
4шт.
6
DK154007-0200
ADAPTER
SN: 86535-UP
1шт.
7
DK020018-1840
BOLT
SN: 86535-UP
1шт.
9
DK154350-1800
PLATE
SN: 86535-UP
1шт.
10
DK020006-1440
BOLT
SN: 86535-UP
5шт.
11
DK020106-1640
BOLT
SN: 86535-UP
1шт.
12
DK154010-0100
SCREW
SN: 86535-UP
1шт.
14
DK155004-4100
SHAFT
SN: 86535-UP
1шт.
15
DK155003-2520
LEVER
SN: 86535-UP
1шт.
16
DK155006-0100
BOLT
SN: 86535-UP
1шт.
19
DK154365-8700
LEVER
SN: 86535-UP
1шт.
21
DK013020-8040
NUT
SN: 86535-UP
2шт.
22
DK154206-3500
COLLAR
SN: 86535-UP
1шт.
23
DK029620-8050
SEAL,OIL
SN: 86535-UP
2шт.
24
DK155404-5700
CAP
SN: 86535-UP
1шт.
25
DK154101-0520
FLYWEIGHT ASS'Y
SN: 86535-UP
1шт.
26
DK025803-1610
KEY, 16MM,WOODRUFF
SN: 86535-UP
1шт.
28
DK029231-2030
NUT
SN: 86535-UP
1шт.
30
DK029311-0180
SHIM, 0.30MM
SN: 86535-UP
-2шт.
30
DK139410-0000
SHIM, 0.50MM
SN: 86535-UP
-2шт.
30
DK029311-0210
SHIM, 1.00MM
SN: 86535-UP
-2шт.
30
DK139410-0100
SHIM, 1.50MM
SN: 86535-UP
-2шт.
32
DK154185-3420
CAPSULE,SPRING
SN: 86535-UP
1шт.
33
DK029201-6080
NUT
SN: 86535-UP
1шт.
34
DK154217-0520
GUIDE LEVER ASS'Y
SN: 86535-UP
1шт.
35
DK016010-0540
RING,SNAP
SN: 86535-UP
1шт.
36
DK029310-5170
SHIM
SN: 86535-UP
4шт.
37
DK025520-1210
PIN,SPLIT
SN: 86535-UP
3шт.
38
DK154234-4020
LINK
SN: 86535-UP
1шт.
39
DK154232-2100
CONNECTOR
SN: 86535-UP
1шт.
40
DK154222-5800
PIN
SN: 86535-UP
1шт.
41
DK155402-3800
PIN,SNAP
SN: 86535-UP
1шт.
43
DK155412-5200
IMPELLER
SN: 86535-UP
1шт.
44
DK154350-7700
GASKET
SN: 86535-UP
1шт.
45
DK154401-3720
LEVER
SN: 86535-UP
1шт.
46
DK154401-1120
LINK
SN: 86535-UP
1шт.
47
DK016010-0540
RING,SNAP
SN: 86535-UP
1шт.
48
DK154222-6200
PIN
SN: 86535-UP
1шт.
49
DK029300-4010
WASHER
SN: 86535-UP
1шт.
50
DK016010-0440
RING,SNAP
SN: 86535-UP
1шт.
51
DK154358-9420
BRACKET
SN: 86535-UP
1шт.
52
DK020118-1640
BOLT
SN: 86535-UP
1шт.
53
DK154011-1100
NUT
SN: 86535-UP
1шт.
54
DK154179-0420
CAPSULE,SPRING
SN: 86535-UP
1шт.
55
DK029201-6010
NUT
SN: 86535-UP
1шт.
57
DK154317-2100
SPRING
SN: 86535-UP
1шт.
58
DK154358-8520
BRACKET
SN: 86535-UP
1шт.
59
DK159248-0200
BOLT
SN: 86535-UP
1шт.
60
DK154156-1000
TUBE
SN: 86535-UP
1шт.
|$0
6137-72-1111
INJECTION PUMP ASS'Y
SN: 86535-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105411-1230
GOVERNOR ASS'Y
SN: 86535-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.
-1шт.
1
DK154004-5020
HOUSING
SN: 86535-UP
1шт.
2
DK154007-2900
PLUG
SN: 86535-UP
1шт.
3
DK154353-4600
GASKET
SN: 86535-UP
1шт.
4
DK154063-7900
COVER
SN: 86535-UP
1шт.
5
DK020006-1640
BOLT
SN: 86535-UP
4шт.
6
DK154007-0200
ADAPTER
SN: 86535-UP
1шт.
7
DK020018-1840
BOLT
SN: 86535-UP
1шт.
9
DK154350-1800
PLATE
SN: 86535-UP
1шт.
10
DK020006-1440
BOLT
SN: 86535-UP
5шт.
11
DK020106-1640
BOLT
SN: 86535-UP
1шт.
12
DK154010-0100
SCREW
SN: 86535-UP
1шт.
14
DK155004-4100
SHAFT
SN: 86535-UP
1шт.
15
DK155003-2520
LEVER
SN: 86535-UP
1шт.
16
DK155006-0100
BOLT
SN: 86535-UP
1шт.
19
DK154365-8700
LEVER
SN: 86535-UP
1шт.
21
DK013020-8040
NUT
SN: 86535-UP
2шт.
22
DK154206-3500
COLLAR
SN: 86535-UP
1шт.
23
DK029620-8050
SEAL,OIL
SN: 86535-UP
2шт.
24
DK155404-5700
CAP
SN: 86535-UP
1шт.
25
DK154101-0520
FLYWEIGHT ASS'Y
SN: 86535-UP
1шт.
26
DK025803-1610
KEY, 16MM,WOODRUFF
SN: 86535-UP
1шт.
28
DK029231-2030
NUT
SN: 86535-UP
1шт.
30
DK029311-0180
SHIM, 0.30MM
SN: 86535-UP
-2шт.
30
DK139410-0000
SHIM, 0.50MM
SN: 86535-UP
-2шт.
30
DK029311-0210
SHIM, 1.00MM
SN: 86535-UP
-2шт.
30
DK139410-0100
SHIM, 1.50MM
SN: 86535-UP
-2шт.
32
DK154185-3420
CAPSULE,SPRING
SN: 86535-UP
1шт.
33
DK029201-6080
NUT
SN: 86535-UP
1шт.
34
DK154217-0520
GUIDE LEVER ASS'Y
SN: 86535-UP
1шт.
35
DK016010-0540
RING,SNAP
SN: 86535-UP
1шт.
36
DK029310-5170
SHIM
SN: 86535-UP
4шт.
37
DK025520-1210
PIN,SPLIT
SN: 86535-UP
3шт.
38
DK154234-4020
LINK
SN: 86535-UP
1шт.
39
DK154232-2100
CONNECTOR
SN: 86535-UP
1шт.
40
DK154222-5800
PIN
SN: 86535-UP
1шт.
41
DK155402-3800
PIN,SNAP
SN: 86535-UP
1шт.
43
DK155412-5200
IMPELLER
SN: 86535-UP
1шт.
44
DK154350-7700
GASKET
SN: 86535-UP
1шт.
45
DK154401-3720
LEVER
SN: 86535-UP
1шт.
46
DK154401-1120
LINK
SN: 86535-UP
1шт.
47
DK016010-0540
RING,SNAP
SN: 86535-UP
1шт.
48
DK154222-6200
PIN
SN: 86535-UP
1шт.
49
DK029300-4010
WASHER
SN: 86535-UP
1шт.
50
DK016010-0440
RING,SNAP
SN: 86535-UP
1шт.
51
DK154358-9420
BRACKET
SN: 86535-UP
1шт.
52
DK020118-1640
BOLT
SN: 86535-UP
1шт.
53
DK154011-1100
NUT
SN: 86535-UP
1шт.
54
DK154179-0420
CAPSULE,SPRING
SN: 86535-UP
1шт.
55
DK029201-6010
NUT
SN: 86535-UP
1шт.
57
DK154317-2100
SPRING
SN: 86535-UP
1шт.
58
DK154358-8520
BRACKET
SN: 86535-UP
1шт.
59
DK159248-0200
BOLT
SN: 86535-UP
1шт.
60
DK154156-1000
TUBE
SN: 86535-UP
1шт.
Выбрано товаров: 142
