Артикул
Название
Примечание
Количество
|$0
6137-72-1111
INJECTION PUMP ASS'Y
SN: 86535-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK101060-2470
PUMP ASS'Y
SN: 86535-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131071-6220
HOUSING
SN: 86535-UP
1шт.
2
DK029040-6020
STUD
SN: 86535-UP
3шт.
3
DK131400-0100
ADAPTER
SN: 86535-UP
1шт.
4
DK131420-0420
BOLT
SN: 86535-UP
1шт.
5
DK131028-6020
COVER
SN: 86535-UP
1шт.
6
DK131011-0800
GASKET
SN: 86535-UP
1шт.
7
DK131017-1000
SCREW
SN: 86535-UP
2шт.
9
DK139206-0400
NUT
SN: 86535-UP
3шт.
11
DK131370-1400
CAMSHAFT
SN: 86535-UP
1шт.
12
DK028201-7020
BEARING
SN: 86535-UP
-2шт.
13
DK131302-0300
RING
SN: 86535-UP
2шт.
14
DK029311-7010
SHIM, 0.1MM
SN: 86535-UP
-2шт.
14
DK029311-7020
SHIM, 0.12MM
SN: 86535-UP
-2шт.
14
DK029311-7030
SHIM, 0.14MM
SN: 86535-UP
-2шт.
14
DK029311-7040
SHIM, 0.16MM
SN: 86535-UP
-2шт.
14
DK029311-7050
SHIM, 0.18MM
SN: 86535-UP
-2шт.
14
DK029311-7090
SHIM, 0.3MM
SN: 86535-UP
-2шт.
14
DK029311-7060
SHIM, 0.5MM
SN: 86535-UP
-2шт.
14
DK029311-7210
SHIM, 0.7MM
SN: 86535-UP
-2шт.
14
DK029311-7070
SHIM, 1.0MM
SN: 86535-UP
-2шт.
14
DK029311-7220
SHIM, 1.4MM
SN: 86535-UP
-2шт.
14
DK139417-0000
SHIM, 2.40MM
SN: 86535-UP
-2шт.
15
DK131306-0800
BEARING,CENTER
SN: 86535-UP
1шт.
16
DK029050-5010
SCREW
SN: 86535-UP
2шт.
17
DK026505-0940
GASKET
SN: 86535-UP
2шт.
18
DK029621-7050
SEAL,OIL
SN: 86535-UP
1шт.
19
DK131330-2600
COVER
SN: 86535-UP
1шт.
20
DK020006-1440
BOLT
SN: 86535-UP
4шт.
21
DK029634-4020
O-RING
SN: 86535-UP
1шт.
23
DK131325-0500
NUT
SN: 86535-UP
1шт.
24
DK023641-2410
WASHER,SPRING
SN: 86535-UP
1шт.
25
DK025803-1610
KEY, 16MM
SN: 86535-UP
1шт.
26
DK029731-4680
BOLT,EYE
SN: 86535-UP
1шт.
|$0
6137-72-1111
INJECTION PUMP ASS'Y
SN: 86535-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK101060-2470
PUMP ASS'Y
SN: 86535-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131071-6220
HOUSING
SN: 86535-UP
1шт.
2
DK029040-6020
STUD
SN: 86535-UP
3шт.
3
DK131400-0100
ADAPTER
SN: 86535-UP
1шт.
4
DK131420-0420
BOLT
SN: 86535-UP
1шт.
5
DK131028-6020
COVER
SN: 86535-UP
1шт.
6
DK131011-0800
GASKET
SN: 86535-UP
1шт.
7
DK131017-1000
SCREW
SN: 86535-UP
2шт.
9
DK139206-0400
NUT
SN: 86535-UP
3шт.
11
DK131370-1400
CAMSHAFT
SN: 86535-UP
1шт.
12
DK028201-7020
BEARING
SN: 86535-UP
-2шт.
13
DK131302-0300
RING
SN: 86535-UP
2шт.
14
DK029311-7010
SHIM, 0.1MM
SN: 86535-UP
-2шт.
14
DK029311-7020
SHIM, 0.12MM
SN: 86535-UP
-2шт.
14
DK029311-7030
SHIM, 0.14MM
SN: 86535-UP
-2шт.
14
DK029311-7040
SHIM, 0.16MM
SN: 86535-UP
-2шт.
14
DK029311-7050
SHIM, 0.18MM
SN: 86535-UP
-2шт.
14
DK029311-7090
SHIM, 0.3MM
SN: 86535-UP
-2шт.
14
DK029311-7060
SHIM, 0.5MM
SN: 86535-UP
-2шт.
14
DK029311-7210
SHIM, 0.7MM
SN: 86535-UP
-2шт.
14
DK029311-7070
SHIM, 1.0MM
SN: 86535-UP
-2шт.
14
DK029311-7220
SHIM, 1.4MM
SN: 86535-UP
-2шт.
14
DK139417-0000
SHIM, 2.40MM
SN: 86535-UP
-2шт.
15
DK131306-0800
BEARING,CENTER
SN: 86535-UP
1шт.
16
DK029050-5010
SCREW
SN: 86535-UP
2шт.
17
DK026505-0940
GASKET
SN: 86535-UP
2шт.
18
DK029621-7050
SEAL,OIL
SN: 86535-UP
1шт.
19
DK131330-2600
COVER
SN: 86535-UP
1шт.
20
DK020006-1440
BOLT
SN: 86535-UP
4шт.
21
DK029634-4020
O-RING
SN: 86535-UP
1шт.
23
DK131325-0500
NUT
SN: 86535-UP
1шт.
24
DK023641-2410
WASHER,SPRING
SN: 86535-UP
1шт.
25
DK025803-1610
KEY, 16MM
SN: 86535-UP
1шт.
26
DK029731-4680
BOLT,EYE
SN: 86535-UP
1шт.
Выбрано товаров: 90
