Запчасти Komatsu S6D105-1AJ ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|$0

6137-72-1112

INJECTION PUMP ASS'Y

SN: 94068-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453,0454, 0463, 0464, 0472 TO 0482.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105661-0371

COUPLING ASS'Y

SN: 94068-UP

1шт.

1

DK156630-0500

COUPLING

SN: 94068-UP

1шт.

2

DK156605-2320

PLATE

SN: 94068-UP

2шт.

3

DK156609-5900

COUPLING,CROSS

SN: 94068-UP

1шт.

4

DK156633-6200

BOLT

SN: 94068-UP

8шт.

5

DK156615-3300

WASHER,LOCK

SN: 94068-UP

2шт.

6

DK029200-8050

NUT

SN: 94068-UP

2шт.

7

DK156633-6000

BOLT

SN: 94068-UP

1шт.
