Артикул
Название
Примечание
Количество
|1
6205-71-1320
INJECTION PUMP ASS'Y
SN: 168012-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0T3 TO A4010-F0T3.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK101049-8900
PUMP ASS'Y
SN: 168012-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B0T3 AND A4010-C0T3.
-1шт.
1
DK131063-9720
HOUSING
SN: 168012-UP
1шт.
3
DK131400-0100
ADAPTER
SN: 168012-UP
1шт.
4
DK131423-0900
ADAPTER
SN: 168012-UP
1шт.
5
DK131028-6220
COVER
SN: 168012-UP
1шт.
6
DK131011-1900
GASKET
SN: 168012-UP
1шт.
7
DK131017-1000
SCREW
SN: 168012-UP
2шт.
9
DK139206-0400
NUT
SN: 168012-UP
3шт.
11
DK131360-2700
CAMSHAFT
SN: 168012-UP
1шт.
|12
DK028201-7020
BEARING
SN: 168012-UP
-2шт.
13
DK131302-0300
RING
SN: 168012-UP
2шт.
14
DK029311-7010
SHIM¤ 0.1MM
SN: 168012-UP
-2шт.
|14
DK029311-7020
SHIM¤ 0.12MM
SN: 168012-UP
-2шт.
|14
DK029311-7030
SHIM¤ 0.14MM
SN: 168012-UP
-2шт.
|14
DK029311-7040
SHIM¤ 0.16MM
SN: 168012-UP
-2шт.
|14
DK029311-7050
SHIM¤ 0.18MM
SN: 168012-UP
-2шт.
|14
DK029311-7090
SHIM¤ 0.3MM
SN: 168012-UP
-2шт.
|14
DK029311-7060
SHIM¤ 0.5MM
SN: 168012-UP
-2шт.
|14
DK029311-7210
SHIM¤ 0.7MM
SN: 168012-UP
-2шт.
|14
DK029311-7070
SHIM¤ 1.0MM
SN: 168012-UP
-2шт.
|14
DK029311-7220
SHIM¤ 1.4MM
SN: 168012-UP
-2шт.
|14
DK139417-0000
SHIM¤ 2.40MM
SN: 168012-UP
-2шт.
15
DK029621-7050
SEAL,OIL
SN: 168012-UP
1шт.
16
DK131330-6200
COVER
SN: 168012-UP
1шт.
17
DK020006-1440
BOLT
SN: 168012-UP
4шт.
18
DK025803-1640
KEY
SN: 168012-UP
1шт.
19
DK131401-0020
BOLT,EYE
SN: 168012-UP
1шт.
21
DK131424-7420
VALVE,OVER FLOW
SN: 168012-UP
1шт.
22
DK139814-0500
EYE
SN: 168012-UP
1шт.
Выбрано товаров: 41
