Запчасти Komatsu S3D84-2BA СТАРТЕР (KW) ЭЛЕКТРИКА

|1

YM129400-77011

STARTING MOTOR ASS'Y,(2KW)

SN: 6789-UP

1шт.

|1

YM129400-77010

STARTING MOTOR ASS'Y,(2KW)

SN: 3826-6788

1шт.

1

YM129400-77401

ARMATURE ASS'Y

SN: 6789-UP

1шт.

|1

YM129400-77400

ARMATURE ASS'Y

SN: 3826-6788

1шт.

2

YM171008-77410

BEARING

SN: 3826-UP

1шт.

3

YM171008-77420

BEARING

SN: 3826-UP

1шт.

4

YM129400-77440

FIELD COIL ASS'Y

SN: 3826-UP

1шт.

5

YM171008-77450

SCREW,POLE CORE

SN: 3826-UP

4шт.

6

YM129400-77460

BRUSH (+)

SN: 3826-UP

2шт.

7

YM129400-77470

BRUSH HOLDER ASS'Y,BRUSH

SN: 3826-UP

1шт.

8

YM129400-77480

BRUSH (-)

SN: 3826-UP

2шт.

9

YM129400-77490

SPRING,BRUSH

SN: 3826-UP

4шт.

10

YM129400-77510

COVER,REAR

SN: 3826-UP

1шт.

11

YM171008-77510

HOUSING ASS'Y,GEAR

SN: 3826-UP

1шт.

12

YM129400-77520

HOUSING,CENTER

SN: 3826-UP

1шт.

13

YM129400-77530

SWITCH,MAGNETIC

SN: 3826-UP

1шт.

14

YM171008-77540

LEVER ASS'Y,SHIFT

SN: 3826-UP

1шт.

15

YM129400-77571

SEAL KIT

SN: 6789-UP

1шт.

|15

YM129400-77570

SEAL KIT

SN: 3826-6788

1шт.

16

YM129400-77640

BOLT,THROUGH

SN: 3826-UP

2шт.

|17

YM171008-77650

PINION ASS'Y

SN: 3826-UP

1шт.

17

YM171008-77660

SHAFT,PINION

SN: 3826-UP

1шт.

18

YM171008-77670

STOPPER,PINION

SN: 3826-UP

1шт.

19

YM171008-77720

CLUTCH ASS'Y

SN: 3826-UP

1шт.

20

YM171008-77730

BEARING,BALL

SN: 3826-UP

1шт.

21

YM171008-77740

BEARING,BALL

SN: 3826-UP

1шт.

22

YM26106-060322

BOLT

SN: 3826-UP

2шт.

23

YM26106-060402

BOLT

SN: 3826-UP

3шт.
