Запчасти Komatsu 6D125-1L ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС) (С ТУРБОНАГНЕТАТЕЛЬ) ТОПЛИВН. СИСТЕМА

|1

6150-71-2321

INJECTION PUMP A.

SN: 14200-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0454A¤0467¤0468¤0474A AND 0484.

-1шт.

|1

0

INJECTION PUMP A.

SN: 10001-14199

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0454¤0467¤0468¤0474 AND 0484.

-1шт.

|$$5

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND092100-1602

FEED PUMP ASS'Y

SN: 14200-UP

1шт.

|1

ND092100-1600

FEED PUMP ASS'Y

SN: 10001-14199

1шт.

1

ND092120-0370

HOUSING,FEED PUMP

SN: 10001-UP

1шт.

2

ND092168-0150

ROD,PUSH

SN: 10001-UP

1шт.

3

ND092121-0011

VALVE,CHECK

SN: 10001-UP

2шт.

4

ND092124-0010

SPRING,CHECK VALVE

SN: 14200-UP

2шт.

|4

ND092124-0020

SPRING,CHECK VALVE

SN: 10001-14199

2шт.

5

ND092125-0010

GASKET

SN: 10001-UP

2шт.

6

ND092126-0010

PLUG

SN: 10001-UP

1шт.

7

ND092130-0220

PUMP ASS'Y,PRIMING

SN: 14200-UP

1шт.

|7

ND092130-0200

PUMP ASS'Y,PRIMING

SN: 10001-14199

1шт.

8

ND092171-0011

PISTON

SN: 14200-UP

1шт.

|8

ND092171-0010

PISTON¤ 21.988MM

SN: 10001-14199

1шт.

9

ND092176-0010

ROLLER,TAPPET

SN: 10001-UP

1шт.

10

ND092178-0040

PIN,ROLLER

SN: 10001-UP

1шт.

11

ND092179-0070

BLOCK,SLIDE

SN: 10001-UP

2шт.

12

ND949072-0940

RING,SNAP

SN: 10001-UP

1шт.

13

ND949018-1240

WASHER¤ 1MM

SN: 10001-UP

1шт.

14

ND092184-0021

PLUG,PISTON CHAMBER

SN: 10001-UP

1шт.

15

ND092223-0070

SCREW

SN: 10001-UP

1шт.

16

ND092220-0040

FILTER,FUEL

SN: 10001-UP

1шт.

17

ND949180-0310

SCREW

SN: 10001-UP

1шт.

18

ND090222-0070

WASHER

SN: 10001-UP

4шт.

19

ND092174-0050

TAPPET

SN: 10001-UP

1шт.

20

ND092182-0060

SPRING,PISTON

SN: 14200-UP

1шт.

|20

ND092182-0020

SPRING,PISTON

SN: 10001-14199

1шт.

21

ND090061-0011

COVER,PRIMING PUMP

SN: 10001-UP

1шт.
