Запчасти Komatsu 6D125-1L ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (С ТУРБОНАГНЕТАТЕЛЬ) ТОПЛИВН. СИСТЕМА

|1

6150-71-2321

INJECTION PUMP A.

SN: 14200-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0454A¤0467¤0468¤0474A AND 0484.

-1шт.

|1

0

INJECTION PUMP A.

SN: 10001-14199

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0454¤0467¤0468¤0474 AND 0484.

-1шт.

|$$5

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND090800-9091

GOVERNOR ASS'Y

SN: 14200-UP

1шт.

|$$7

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0467 AND 0468.

-1шт.

|1

ND090800-9090

GOVERNOR ASS'Y

SN: 10001-14199

1шт.

|$$9

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0467 AND 0468.

-1шт.

1

ND091011-1690

COVER,GOVERNOR

SN: 10001-UP

1шт.

2

ND091031-0150

NUT,CAP

SN: 10001-UP

1шт.

3

ND091006-0150

SCREW,ADJUST

SN: 10001-UP

1шт.

4

ND090944-0310

BUSHING

SN: 10001-UP

1шт.

5

ND090989-0010

SHAFT,SUPPORT

SN: 10001-UP

1шт.

6

ND090991-0010

PLUG

SN: 10001-UP

2шт.

7

ND090560-0200

CAPSULE,FULL STOP

SN: 10001-UP

1шт.

8

ND090923-0060

NUT

SN: 10001-UP

1шт.

9

ND090880-0120

LEVER,SWIVEL

SN: 10001-UP

1шт.

10

ND090892-0080

BUSHING

SN: 10001-UP

2шт.

11

ND90801-20160

O-RING

SN: 10001-UP

2шт.

12

ND949071-0090

WASHER,SNAP

SN: 10001-UP

2шт.

13

ND949047-1760

BOLT

SN: 10001-UP

4шт.

14

ND949047-1750

BOLT

SN: 10001-UP

2шт.

15

ND949150-0210

SEAL,OIL

SN: 10001-UP

1шт.

16

ND091071-1420

LEVER,ADJUST

SN: 10001-UP

1шт.

|17

ND091070-1860

LEVER ASS'Y,ADJUST

SN: 10001-UP

1шт.

17

ND091071-2640

LEVER,ADJUST

SN: 10001-UP

1шт.

18

ND091070-1050

LEVER

SN: 10001-UP

1шт.

19

ND91518-08161

BOLT

SN: 10001-UP

2шт.

20

ND092417-0010

WASHER

SN: 10001-UP

1шт.

21

ND949047-1190

BOLT

SN: 10001-UP

1шт.

22

ND091094-0060

CAP

SN: 10001-UP

1шт.

23

ND949040-1140

BOLT

SN: 10001-UP

2шт.

24

ND90258-06001

WASHER,SPRING

SN: 10001-UP

1шт.

25

ND091051-0500

PLATE

SN: 10001-UP

1шт.

26

ND949047-1770

BOLT

SN: 10001-UP

2шт.

27

ND91418-06161

BOLT

SN: 10001-UP

2шт.

28

ND090241-0010

WASHER¤ 1.6MM

SN: 10001-UP

2шт.

29

ND091031-0030

NUT,CAP

SN: 10001-UP

1шт.

30

ND949062-1270

PACKING

SN: 10001-UP

1шт.

31

ND090560-0130

CAPSULE,FULL STOP

SN: 10001-UP

1шт.

32

ND948053-0090

NUT

SN: 10001-UP

1шт.

33

ND949130-0030

KEY,WOODRUFF

SN: 10001-UP

1шт.

34

ND090975-0670

ARM,SPRING

SN: 10001-UP

1шт.

35

ND091041-0130

SPRING,RETURN

SN: 10001-UP

1шт.

36

ND949050-1020

NUT

SN: 10001-UP

1шт.

37

ND949018-1020

WASHER¤ 1.0MM

SN: 10001-UP

2шт.

38

ND90801-10120

O-RING

SN: 10001-UP

1шт.
