Артикул
Название
Примечание
Количество
|1
6150-71-1323
INJECTION PUMP A.
SN: 35932-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A¤0461¤0462¤0471A AND 0481.
-1шт.
|1
0
INJECTION PUMP A.
SN: 14186-35931
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A¤0461¤0462¤0471A AND 0481.
-1шт.
|1
0
INJECTION PUMP A.
SN: 10001-14185
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0461¤0462¤0471 AND FIGS.0481.
-1шт.
|$$7
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
ND092120-0370
HOUSING,FEED PUMP
SN: 10001-UP
1шт.
2
ND092168-0150
ROD,PUSH
SN: 10001-UP
1шт.
|4
ND092124-0020
SPRING,CHECK VALVE
SN: 10001-14185
2шт.
6
ND092126-0010
PLUG
SN: 10001-UP
1шт.
|7
ND092130-0200
PUMP ASS'Y,PRIMING
SN: 10001-14185
1шт.
8
ND092171-0011
PISTON
SN: 14186-UP
1шт.
|8
ND092171-0010
PISTON¤ 21.988MM
SN: 10001-14185
1шт.
9
ND092176-0010
ROLLER,TAPPET
SN: 10001-UP
1шт.
10
ND092178-0040
PIN,ROLLER
SN: 10001-UP
1шт.
11
ND092179-0070
BLOCK,SLIDE
SN: 10001-UP
2шт.
12
ND949072-0940
RING,SNAP
SN: 10001-UP
1шт.
14
ND092184-0021
PLUG,PISTON CHAMBER
SN: 10001-UP
1шт.
15
ND092223-0070
SCREW
SN: 10001-UP
1шт.
19
ND092174-0050
TAPPET
SN: 10001-UP
1шт.
20
ND092182-0060
SPRING,PISTON
SN: 14186-UP
1шт.
|20
ND092182-0020
SPRING,PISTON
SN: 10001-14185
1шт.
21
ND090061-0011
COVER,PRIMING PUMP
SN: 10001-UP
1шт.
Выбрано товаров: 34
