Артикул
Название
Примечание
Количество
|1
6150-71-1323
INJECTION PUMP A.
SN: 35932-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A¤0461¤0462¤0471A AND 0481.
-1шт.
|1
0
INJECTION PUMP A.
SN: 14186-35931
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A¤0461¤0462¤0471A AND 0481.
-1шт.
|1
0
INJECTION PUMP A.
SN: 10001-14185
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0461¤0462¤0471 AND FIGS.0481.
-1шт.
|$$7
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090800-8461
GOVERNOR ASS'Y
SN: 35932-UP
1шт.
|$$9
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.
-1шт.
|1
ND090800-8460
GOVERNOR ASS'Y
SN: 10001-35931
1шт.
|$$11
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.
-1шт.
1
ND190890-0120
COVER
SN: 10001-UP
1шт.
2
ND091031-0150
NUT,CAP
SN: 10001-UP
1шт.
3
ND091006-0150
SCREW,ADJUST
SN: 10001-UP
1шт.
4
ND090944-0310
BUSHING
SN: 10001-UP
1шт.
6
ND090991-0010
PLUG
SN: 10001-UP
2шт.
7
ND090560-0200
CAPSULE,FULL STOP
SN: 10001-UP
1шт.
8
ND090923-0060
NUT
SN: 10001-UP
1шт.
9
ND090880-0120
LEVER,SWIVEL
SN: 10001-UP
1шт.
10
ND090892-0150
BUSHING,LEVER
SN: 10001-UP
2шт.
12
ND949071-0090
WASHER,SNAP
SN: 10001-UP
2шт.
13
ND949047-1760
BOLT
SN: 10001-UP
4шт.
14
ND949047-1750
BOLT
SN: 10001-UP
2шт.
16
ND091071-1420
LEVER,ADJUSTING
SN: 10001-UP
1шт.
|17
ND091070-1860
LEVER ASS'Y,ADJUSTING
SN: 10001-UP
1шт.
17
ND091071-2640
LEVER,ADJUSTING
SN: 10001-UP
1шт.
18
ND091070-1050
LEVER
SN: 10001-UP
1шт.
19
ND91518-08161
BOLT
SN: 10001-UP
2шт.
20
ND092417-0010
WASHER
SN: 10001-UP
1шт.
21
ND949047-1190
BOLT
SN: 10001-UP
1шт.
22
ND091094-0060
CAP,LEVER
SN: 10001-UP
1шт.
23
ND949047-2700
BOLT
SN: 10001-UP
1шт.
24
ND091051-0500
PLATE
SN: 10001-UP
1шт.
25
ND949047-1770
BOLT
SN: 10001-UP
3шт.
26
ND91418-06161
BOLT
SN: 10001-UP
2шт.
27
ND090241-0010
WASHER¤ 1.6MM
SN: 10001-UP
2шт.
28
ND091031-0030
NUT
SN: 10001-UP
1шт.
29
ND949062-1650
PACKING,RUBBER
SN: 10001-UP
1шт.
30
ND090560-0131
CAPSULE,FULL STOP
SN: 10001-UP
1шт.
31
ND948053-0090
NUT
SN: 10001-UP
1шт.
32
ND949130-0030
KEY,WOODRUFF
SN: 10001-UP
1шт.
33
ND090975-0670
ARM
SN: 10001-UP
1шт.
36
ND949013-8210
WASHER¤ 0.3MM
SN: 10001-UP
-2шт.
|36
ND949013-8220
WASHER¤ 0.6MM
SN: 10001-UP
-2шт.
|36
ND949013-8230
WASHER¤ 0.9MM
SN: 10001-UP
-2шт.
37
ND949050-1020
NUT
SN: 10001-UP
1шт.
38
ND949018-1020
WASHER¤ 1.0MM
SN: 10001-UP
2шт.
39
ND949140-5740
O-RING
SN: 10001-UP
1шт.
Выбрано товаров: 54
