Артикул
Название
Примечание
Количество
|1
6150-71-1221
INJECTION PUMP A.
SN: 35935-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 29457-35934
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453A TO 0482.
-1шт.
|$$4
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND190800-1301
GOVERNOR ASS'Y
SN: 35935-UP
1шт.
|1
ND190800-1300
GOVERNOR ASS'Y
SN: 29457-35934
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463A AND 0464A.
-1шт.
1
ND090811-0810
HOUSING
SN: 29457-UP
1шт.
2
ND090878-0030
PLATE
SN: 29457-UP
1шт.
3
ND091024-0031
SCREW,ADJUST
SN: 29457-UP
2шт.
4
ND090901-0200
LEVER ASS'Y,TENSION
SN: 29457-UP
1шт.
5
ND090930-0510
LEVER ASS'Y,CONTROL
SN: 29457-UP
1шт.
6
ND90400-02101
E-RING
SN: 29457-UP
1шт.
7
ND948053-0051
NUT
SN: 29457-UP
2шт.
8
ND091046-0010
SLIDER
SN: 29457-UP
1шт.
9
ND090970-0170
SHACKLE ASS'Y
SN: 29457-UP
1шт.
10
ND949130-0050
KEY
SN: 29457-UP
1шт.
11
ND090840-0520
FLYWEIGHT ASS'Y
SN: 29457-UP
1шт.
12
ND949015-0500
WASHER¤ 2.5MM,SPRING
SN: 29457-UP
1шт.
15
ND090868-0040
PLATE,THRUST
SN: 29457-UP
1шт.
16
ND90567-30000
RING,SNAP
SN: 29457-UP
1шт.
17
ND949013-4090
WASHER¤ 0.1MM
SN: 29457-UP
-2шт.
|17
ND949013-4060
WASHER¤ 0.2MM
SN: 29457-UP
-2шт.
|17
ND949013-4070
WASHER¤ 0.3MM
SN: 29457-UP
-2шт.
|17
ND949013-4080
WASHER¤ 0.4MM
SN: 29457-UP
-2шт.
|17
ND949013-4100
WASHER¤ 1.0MM
SN: 29457-UP
-2шт.
18
ND090992-0410
SPRING,SPEED CONTROL
SN: 29457-UP
1шт.
19
ND090993-0260
SPRING,START
SN: 29457-UP
1шт.
|20
ND090910-1220
ADAPTER ASS'Y
SN: 29457-UP
1шт.
20
ND090911-0010
SCREW,ADJUST
SN: 29457-UP
1шт.
21
ND090919-0010
ADAPTER
SN: 29457-UP
1шт.
22
ND090918-0380
SPRING
SN: 29457-UP
1шт.
23
ND090894-0010
E-RING
SN: 29457-UP
1шт.
24
ND949013-3880
WASHER¤ 0.1MM
SN: 29457-UP
-2шт.
|24
ND949013-4040
WASHER¤ 0.2MM
SN: 29457-UP
-2шт.
|24
ND949013-4020
WASHER¤ 0.25MM
SN: 29457-UP
-2шт.
|24
ND949013-4030
WASHER¤ 0.5MM
SN: 29457-UP
-2шт.
25
ND090923-0011
NUT,LOCK
SN: 29457-UP
1шт.
26
ND090224-0140
PLUG
SN: 29457-UP
1шт.
28
ND090823-0240
GASKET
SN: 29457-UP
1шт.
29
ND090823-0180
GASKET
SN: 29457-UP
1шт.
30
ND090245-0230
SCREW
SN: 29457-UP
1шт.
32
ND091013-0050
JOINT
SN: 35935-UP
1шт.
33
ND091014-0080
PIN,STOP
SN: 35935-UP
1шт.
34
ND91518-08221
BOLT
SN: 29457-UP
1шт.
35
ND91418-06161
BOLT
SN: 29457-UP
6шт.
Выбрано товаров: 50
