Артикул
Название
Примечание
Количество
|1
6150-71-1221
INJECTION PUMP A.
SN: 35935-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 29457-35934
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453A TO 0482.
-1шт.
|$$4
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-7580
BODY ASS'Y
SN: 29457-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453A AND 0454A.
-1шт.
1
ND090131-0650
HOLDER
SN: 29457-UP
6шт.
2
ND090133-0260
STOPPER
SN: 29457-UP
6шт.
3
ND090136-0800
SPRING
SN: 29457-UP
6шт.
4
ND090137-0100
GASKET
SN: 29457-UP
6шт.
5
ND090140-1660
VALVE
SN: 29457-UP
6шт.
6
ND090150-3950
ELEMENT
SN: 29457-UP
6шт.
7
ND090156-0010
PINION,CONTROL
SN: 29457-UP
6шт.
8
ND090157-0010
SCREW
SN: 29457-UP
6шт.
9
ND090161-0330
SLEEVE
SN: 29457-UP
6шт.
10
ND090163-0010
SEAT,UPPER
SN: 29457-UP
6шт.
11
ND090164-0090
SPRING,PLUNGER
SN: 29457-UP
6шт.
12
ND090165-0160
SEAT,LOWER
SN: 29457-UP
6шт.
|13
ND090170-0070
TAPPET ASS'Y
SN: 29457-UP
6шт.
13
ND090176-0050
PIN
SN: 29457-UP
1шт.
14
ND090169-0070
BODY
SN: 29457-UP
1шт.
15
ND090178-0030
BUSHING
SN: 29457-UP
1шт.
16
ND090181-0030
ROLLER
SN: 29457-UP
1шт.
17
ND949070-0111
RING,SNAP
SN: 29457-UP
1шт.
18
ND090189-0090
PLUG
SN: 29457-UP
6шт.
19
ND090212-0010
RACK,CONTROL
SN: 29457-UP
1шт.
20
ND090215-0011
SCREW
SN: 29457-UP
1шт.
21
ND090230-0050
PLATE
SN: 29457-UP
3шт.
22
ND949047-2220
BOLT
SN: 29457-UP
3шт.
23
ND090311-0100
SHIM¤ 0.1MM
SN: 29457-UP
-2шт.
|23
ND090311-0150
SHIM¤ 0.15MM
SN: 29457-UP
-2шт.
|23
ND090311-0110
SHIM¤ 0.2MM
SN: 29457-UP
-2шт.
|23
ND090311-0120
SHIM¤ 0.3MM
SN: 29457-UP
-2шт.
|23
ND090311-0130
SHIM¤ 0.4MM
SN: 29457-UP
-2шт.
|23
ND090311-0140
SHIM¤ 0.5MM
SN: 29457-UP
-2шт.
|23
ND090311-0010
SHIM¤ 0.6MM
SN: 29457-UP
-2шт.
|23
ND090311-0020
SHIM¤ 0.7MM
SN: 29457-UP
-2шт.
|23
ND090311-0030
SHIM¤ 0.8MM
SN: 29457-UP
-2шт.
|23
ND090311-0040
SHIM¤ 0.9MM
SN: 29457-UP
-2шт.
|23
ND090311-0050
SHIM¤ 1.0MM
SN: 29457-UP
-2шт.
|23
ND090311-0060
SHIM¤ 1.1MM
SN: 29457-UP
-2шт.
|23
ND090311-0070
SHIM¤ 1.2MM
SN: 29457-UP
-2шт.
|23
ND090311-0080
SHIM¤ 1.3MM
SN: 29457-UP
-2шт.
|23
ND090311-0090
SHIM¤ 1.4MM
SN: 29457-UP
-2шт.
25
ND090018-0120
COVER
SN: 29457-UP
1шт.
Выбрано товаров: 46
