Запчасти Komatsu 6D125-1DD ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№97-) ТОПЛИВН. СИСТЕМА

|1

6150-71-1221

INJECTION PUMP A.

SN: 35935-UP

1шт.

|1

0

INJECTION PUMP A.

SN: 29457-35934

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453A TO 0482.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-1301

GOVERNOR ASS'Y

SN: 35935-UP

1шт.

|1

ND190800-1300

GOVERNOR ASS'Y

SN: 29457-35934

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0463A AND 0464A.

-1шт.

1

ND090811-0810

HOUSING

SN: 29457-UP

1шт.

2

ND090878-0030

PLATE

SN: 29457-UP

1шт.

3

ND091024-0031

SCREW,ADJUST

SN: 29457-UP

2шт.

4

ND090901-0200

LEVER ASS'Y,TENSION

SN: 29457-UP

1шт.

5

ND090930-0510

LEVER ASS'Y,CONTROL

SN: 29457-UP

1шт.

6

ND90400-02101

E-RING

SN: 29457-UP

1шт.

7

ND948053-0051

NUT

SN: 29457-UP

2шт.

8

ND091046-0010

SLIDER

SN: 29457-UP

1шт.

9

ND090970-0170

SHACKLE ASS'Y

SN: 29457-UP

1шт.

10

ND949130-0050

KEY

SN: 29457-UP

1шт.

11

ND090840-0520

FLYWEIGHT ASS'Y

SN: 29457-UP

1шт.

12

ND949015-0500

WASHER¤ 2.5MM,SPRING

SN: 29457-UP

1шт.

13

ND090844-0010

NUT

SN: 29457-UP

1шт.

14

ND090860-0200

SLEEVE SUB ASS'Y

SN: 29457-UP

1шт.

15

ND090868-0040

PLATE,THRUST

SN: 29457-UP

1шт.

16

ND90567-30000

RING,SNAP

SN: 29457-UP

1шт.

17

ND949013-4090

WASHER¤ 0.1MM

SN: 29457-UP

-2шт.

|17

ND949013-4060

WASHER¤ 0.2MM

SN: 29457-UP

-2шт.

|17

ND949013-4070

WASHER¤ 0.3MM

SN: 29457-UP

-2шт.

|17

ND949013-4080

WASHER¤ 0.4MM

SN: 29457-UP

-2шт.

|17

ND949013-4100

WASHER¤ 1.0MM

SN: 29457-UP

-2шт.

18

ND090992-0410

SPRING,SPEED CONTROL

SN: 29457-UP

1шт.

19

ND090993-0260

SPRING,START

SN: 29457-UP

1шт.

|20

ND090910-1220

ADAPTER ASS'Y

SN: 29457-UP

1шт.

20

ND090911-0010

SCREW,ADJUST

SN: 29457-UP

1шт.

21

ND090919-0010

ADAPTER

SN: 29457-UP

1шт.

22

ND090918-0380

SPRING

SN: 29457-UP

1шт.

23

ND090894-0010

E-RING

SN: 29457-UP

1шт.

24

ND949013-3880

WASHER¤ 0.1MM

SN: 29457-UP

-2шт.

|24

ND949013-4040

WASHER¤ 0.2MM

SN: 29457-UP

-2шт.

|24

ND949013-4020

WASHER¤ 0.25MM

SN: 29457-UP

-2шт.

|24

ND949013-4030

WASHER¤ 0.5MM

SN: 29457-UP

-2шт.

25

ND090923-0011

NUT,LOCK

SN: 29457-UP

1шт.

26

ND090224-0140

PLUG

SN: 29457-UP

1шт.

27

ND949018-1550

WASHER

SN: 29457-UP

1шт.

28

ND090823-0240

GASKET

SN: 29457-UP

1шт.

29

ND090823-0180

GASKET

SN: 29457-UP

1шт.

30

ND090245-0230

SCREW

SN: 29457-UP

1шт.

31

ND090222-0120

WASHER

SN: 29457-UP

2шт.

32

ND091013-0050

JOINT

SN: 35935-UP

1шт.

33

ND091014-0080

PIN,STOP

SN: 35935-UP

1шт.

34

ND91518-08221

BOLT

SN: 29457-UP

1шт.

35

ND91418-06161

BOLT

SN: 29457-UP

6шт.
