Запчасти Komatsu 6D125-1B-P ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

1

6150-71-1113

INJECTION PUMP A.

SN: 37408-UP

1шт.

1

0

INJECTION PUMP A.

SN: 11755-37407

1шт.

1

0

INJECTION PUMP A.

SN: 10001-11754

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$5

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

ND090100-6091

BODY ASS'Y

SN: 37408-UP

1шт.

1

ND090100-5500

BODY ASS'Y

SN: 10001-37407

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.

-1шт.

1

ND090130-0171

HOLDER,DELIVERY VALVE

SN: 37408-UP

6шт.

1

ND090130-0240

HOLDER,DELIVERY VALVE

SN: 10001-37407

6шт.

2

ND090136-0870

SPRING,DELIVERY VALVE

SN: 37408-UP

6шт.

2

ND090136-0660

SPRING,DELIVERY VALVE

SN: 10001-37407

6шт.

3

ND949140-2570

O-RING

SN: 10001-UP

6шт.

4

ND090140-1430

VALVE SUB ASS'Y,DELIVERY

SN: 10001-UP

6шт.

5

ND090150-3250

ELEMENT

SN: 10001-UP

6шт.

6

ND090160-0060

SLEEVE,CONTROL

SN: 10001-UP

6шт.

7

ND090212-0471

RACK,CONTROL

SN: 37408-UP

1шт.

7

ND090212-0470

RACK,CONTROL

SN: 10001-37407

1шт.

8

ND090163-0131

SEAT,SPRING¤ UPPER

SN: 10001-UP

6шт.

9

ND090164-0250

SPRING,PLUNGER

SN: 37408-UP

6шт.

9

ND090164-0211

SPRING,PLUNGER

SN: 10001-37407

6шт.

10

ND090165-0150

SEAT,SPRING¤ LOWER

SN: 10001-UP

6шт.

11

ND090170-0230

TAPPET ASS'Y

SN: 10001-UP

6шт.

12

ND090438-0860

SHIM¤ 1.35MM

SN: 10001-37407

-2шт.

12

ND090438-0620

SHIM¤ 1.4MM

SN: 10001-37407

-2шт.

12

ND090438-0870

SHIM¤ 1.45MM

SN: 10001-37407

-2шт.

12

ND090438-0630

SHIM¤ 1.5MM

SN: 10001-37407

-2шт.

12

ND090438-0880

SHIM¤ 1.55MM

SN: 10001-37407

-2шт.

12

ND090438-0890

SHIM¤ 1.6MM

SN: 10001-37407

-2шт.

12

ND090438-0900

SHIM¤ 1.65MM

SN: 10001-37407

-2шт.

12

ND090438-0910

SHIM¤ 1.7MM

SN: 10001-37407

-2шт.

12

ND090438-0390

SHIM¤ 1.75MM

SN: 10001-UP

-2шт.

12

ND090438-0400

SHIM¤ 1.8MM

SN: 10001-UP

-2шт.

12

ND090438-0410

SHIM¤ 1.85MM

SN: 10001-UP

-2шт.

12

ND090438-0420

SHIM¤ 1.9MM

SN: 10001-UP

-2шт.

12

ND090438-0430

SHIM¤ 1.95MM

SN: 10001-UP

-2шт.

12

ND090438-0440

SHIM¤ 2.0MM

SN: 37408-UP

-2шт.

12

ND090438-0450

SHIM¤ 2.05MM

SN: 37408-UP

-2шт.

12

ND090438-0460

SHIM¤ 2.1MM

SN: 37408-UP

-2шт.

12

ND090438-0470

SHIM¤ 2.15MM

SN: 37408-UP

-2шт.

12

ND090438-0480

SHIM¤ 2.2MM

SN: 37408-UP

-2шт.

12

ND090438-0490

SHIM¤ 2.25MM

SN: 37408-UP

-2шт.

12

ND090438-0500

SHIM¤ 2.3MM

SN: 37408-UP

-2шт.

12

ND090438-0510

SHIM¤ 2.35MM

SN: 37408-UP

-2шт.

12

ND090438-0520

SHIM¤ 2.4MM

SN: 37408-UP

-2шт.

13

ND949013-5880

WASHER

SN: 10001-UP

12шт.

14

ND090139-0020

O-RING

SN: 10001-UP

18шт.

15

ND949018-1730

WASHER

SN: 10001-UP

6шт.

16

ND090215-0011

SCREW

SN: 37408-UP

1шт.

16

ND090215-0021

SCREW

SN: 10001-37407

1шт.

17

ND090114-0110

BUSHING

SN: 10001-UP

2шт.

18

ND090367-0040

BUSHING

SN: 10001-UP

1шт.

19

ND090431-0060

COVER

SN: 37408-UP

1шт.

20

ND091403-0110

WASHER

SN: 37408-UP

2шт.

21

ND090018-0410

COVER

SN: 10001-UP

1шт.

22

ND949018-1550

WASHER

SN: 10001-UP

1шт.
