Артикул
Название
Примечание
Количество
|1
6150-71-1113
INJECTION PUMP A.
SN: 37408-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 11755-37407
1шт.
|1
0
INJECTION PUMP A.
SN: 10001-11754
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$5
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-6091
BODY ASS'Y
SN: 37408-UP
1шт.
|1
ND090100-5500
BODY ASS'Y
SN: 10001-37407
1шт.
|$$8
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
ND090130-0171
HOLDER,DELIVERY VALVE
SN: 37408-UP
6шт.
|1
ND090130-0240
HOLDER,DELIVERY VALVE
SN: 10001-37407
6шт.
2
ND090136-0870
SPRING,DELIVERY VALVE
SN: 37408-UP
6шт.
|2
ND090136-0660
SPRING,DELIVERY VALVE
SN: 10001-37407
6шт.
5
ND090150-3250
ELEMENT
SN: 10001-UP
6шт.
6
ND090160-0060
SLEEVE,CONTROL
SN: 10001-UP
6шт.
7
ND090212-0471
RACK,CONTROL
SN: 37408-UP
1шт.
|7
ND090212-0470
RACK,CONTROL
SN: 10001-37407
1шт.
8
ND090163-0131
SEAT,SPRING¤ UPPER
SN: 10001-UP
6шт.
9
ND090164-0250
SPRING,PLUNGER
SN: 37408-UP
6шт.
|9
ND090164-0211
SPRING,PLUNGER
SN: 10001-37407
6шт.
10
ND090165-0150
SEAT,SPRING¤ LOWER
SN: 10001-UP
6шт.
11
ND090170-0230
TAPPET ASS'Y
SN: 10001-UP
6шт.
12
ND090438-0860
SHIM¤ 1.35MM
SN: 10001-37407
-2шт.
|12
ND090438-0620
SHIM¤ 1.4MM
SN: 10001-37407
-2шт.
|12
ND090438-0870
SHIM¤ 1.45MM
SN: 10001-37407
-2шт.
|12
ND090438-0630
SHIM¤ 1.5MM
SN: 10001-37407
-2шт.
|12
ND090438-0880
SHIM¤ 1.55MM
SN: 10001-37407
-2шт.
|12
ND090438-0890
SHIM¤ 1.6MM
SN: 10001-37407
-2шт.
|12
ND090438-0900
SHIM¤ 1.65MM
SN: 10001-37407
-2шт.
|12
ND090438-0910
SHIM¤ 1.7MM
SN: 10001-37407
-2шт.
|12
ND090438-0390
SHIM¤ 1.75MM
SN: 10001-UP
-2шт.
|12
ND090438-0400
SHIM¤ 1.8MM
SN: 10001-UP
-2шт.
|12
ND090438-0410
SHIM¤ 1.85MM
SN: 10001-UP
-2шт.
|12
ND090438-0420
SHIM¤ 1.9MM
SN: 10001-UP
-2шт.
|12
ND090438-0430
SHIM¤ 1.95MM
SN: 10001-UP
-2шт.
|12
ND090438-0440
SHIM¤ 2.0MM
SN: 37408-UP
-2шт.
|12
ND090438-0450
SHIM¤ 2.05MM
SN: 37408-UP
-2шт.
|12
ND090438-0460
SHIM¤ 2.1MM
SN: 37408-UP
-2шт.
|12
ND090438-0470
SHIM¤ 2.15MM
SN: 37408-UP
-2шт.
|12
ND090438-0480
SHIM¤ 2.2MM
SN: 37408-UP
-2шт.
|12
ND090438-0490
SHIM¤ 2.25MM
SN: 37408-UP
-2шт.
|12
ND090438-0500
SHIM¤ 2.3MM
SN: 37408-UP
-2шт.
|12
ND090438-0510
SHIM¤ 2.35MM
SN: 37408-UP
-2шт.
|12
ND090438-0520
SHIM¤ 2.4MM
SN: 37408-UP
-2шт.
16
ND090215-0011
SCREW
SN: 37408-UP
1шт.
|16
ND090215-0021
SCREW
SN: 10001-37407
1шт.
18
ND090367-0040
BUSHING
SN: 10001-UP
1шт.
19
ND090431-0060
COVER
SN: 37408-UP
1шт.
20
ND091403-0110
WASHER
SN: 37408-UP
2шт.
21
ND090018-0410
COVER
SN: 10001-UP
1шт.
Выбрано товаров: 56
