Запчасти Komatsu 6D125-1AB КОМПРЕССОР (ВНУТР. ЧАСТИ)(№7-) АКСЕССУАРЫ

|1

6151-81-3111

AIR COMPRESSOR A.

SN: 40173-UP

1шт.

|$$2

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

DK487000-5800

CASE,CRANK

SN: 40173-UP

1шт.

2

DK487008-8301

CRANKSHAFT

SN: 40173-UP

1шт.

3

DK035620-9000

BEARING

SN: 40173-UP

2шт.

4

DK029623-8040

SEAL,OIL (K8)

SN: 40173-UP

1шт.

5

DK487003-8120

COVER,BEARING

SN: 40173-UP

1шт.

6

DK487061-2500

O-RING (K8)

SN: 40173-UP

1шт.

7

DK487061-3700

O-RING (K8)

SN: 40173-UP

1шт.

8

DK487001-2700

CYLINDER

SN: 40173-UP

1шт.

9

DK487013-1820

CONNECTING ROD A.

SN: 40173-UP

1шт.

|9

DK029300-8490

WASHER

SN: 40173-UP

2шт.

|9

DK029200-8130

NUT

SN: 40173-UP

2шт.

10

DK487009-2000

PISTON

SN: 40173-UP

1шт.

11

DK487010-4720

RING KIT,PISTON

SN: 40173-UP

1шт.

12

DK487012-0100

PIN,PISTON

SN: 40173-UP

1шт.

13

DK016110-1610

RING,SNAP

SN: 40173-UP

2шт.

14

DK487020-2100

GASKET (K8)

SN: 40173-UP

1шт.

|15

DK487018-4420

CYLINDER HEAD ASS'Y

SN: 40173-UP

1шт.

15

DK487018-4320

HEAD,CYLINDER

SN: 40173-UP

1шт.

|15

DK487028-1601

GUIDE,INTAKE VALVE

SN: 40173-UP

1шт.

|15

DK487027-1100

SPRING,INTAKE VALVE

SN: 40173-UP

1шт.

|15

DK487026-1601

VALVE,PLATE¤ INTAKE VALVE

SN: 40173-UP

2шт.

|15

DK487025-0900

SEAT,INTAKE VALVE

SN: 40173-UP

1шт.

|15

DK029333-8020

GASKET,INTAKE VALVE (K8)

SN: 40173-UP

2шт.

|15

DK487042-1000

GUIDE,SPRING¤ DELIVERY VALVE

SN: 40173-UP

1шт.

|15

DK487032-2700

GUIDE,DELIVERY VALVE

SN: 40173-UP

1шт.

|15

DK487031-1800

SPRING,DELIVERY VALVE

SN: 40173-UP

1шт.

|15

DK487030-2000

SEAT,DELIVERY VALVE

SN: 40173-UP

1шт.

|15

DK487039-0200

GASKET,DELIVERY VALVE (K8)

SN: 40173-UP

1шт.

16

DK029312-4070

SHIM (K8)

SN: 40173-UP

1шт.

17

DK487021-2020

UNLOADER VALVE A.

SN: 40173-UP

1шт.

18

DK156603-4400

BOLT

SN: 40173-UP

4шт.

19

DK010110-2570

BOLT

SN: 40173-UP

4шт.

20

DK487088-0000

BOLT

SN: 40173-UP

4шт.

21

DK014110-8440

WASHER,SPRING

SN: 40173-UP

4шт.

22

DK014111-0440

WASHER,SPRING

SN: 40173-UP

4шт.

23

DK014020-8140

WASHER

SN: 40173-UP

4шт.

24

DK487093-0000

ADAPTER

SN: 40173-UP

1шт.

25

DK010006-1270

BOLT

SN: 40173-UP

2шт.

26

DK014110-6440

WASHER,SPRING

SN: 40173-UP

2шт.
