Артикул
Название
Примечание
Количество
|1
6150-71-2611
INJECTION PUMP A.
SN: .-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 10276-.
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.
-1шт.
|$$4
THE NIPPON DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-6710
BODY ASS'Y
SN: 10276-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 AND 0454.
-1шт.
1
ND090110-3741
HOUSING,PUMP
SN: 10276-UP
1шт.
2
ND949043-0010
STUD
SN: 10276-UP
3шт.
3
ND949140-0970
O-RING
SN: 10276-UP
1шт.
6
ND090193-0050
RING,ADJUST
SN: 10276-UP
1шт.
7
ND090194-0070
PLATE¤ 0.1MM
SN: 10276-UP
-2шт.
|7
ND090194-0080
PLATE¤ 0.15MM
SN: 10276-UP
-2шт.
|7
ND090194-0090
PLATE¤ 0.3MM
SN: 10276-UP
-2шт.
|7
ND090194-0100
PLATE¤ 0.5MM
SN: 10276-UP
-2шт.
9
ND090201-0430
COVER,BEARING
SN: 10276-UP
1шт.
10
ND949047-1380
BOLT
SN: 10276-UP
4шт.
13
ND090248-0010
WASHER
SN: 10276-UP
2шт.
14
ND090317-0140
PLUG
SN: 10276-UP
1шт.
15
ND090193-0060
RING,ADJUST
SN: 10276-UP
1шт.
16
ND090118-0250
NEEDLE,TIMING
SN: 10276-UP
1шт.
21
ND090194-0300
PLATE¤ 0.1MM
SN: 10276-UP
-2шт.
|21
ND090194-0310
PLATE¤ 0.16MM
SN: 10276-UP
-2шт.
|21
ND090194-0320
PLATE¤ 0.3MM
SN: 10276-UP
-2шт.
|21
ND090194-0330
PLATE¤ 0.5MM
SN: 10276-UP
-2шт.
22
ND949047-0620
BOLT
SN: 10276-UP
2шт.
24
ND090012-0140
NUT,ROUND
SN: 10276-UP
1шт.
25
ND949014-0070
WASHER,SPRING
SN: 10276-UP
1шт.
27
ND090310-0080
VALVE ASS'Y,OVER FLOW
SN: 10276-UP
1шт.
28
ND90458-05750
KEY
SN: 10276-UP
1шт.
Выбрано товаров: 40
