Артикул
Название
Примечание
Количество
|$0
6136-72-1410
INJECTION PUMP ASS'Y
SN: 50001-UP
1шт.
|$1
6136-72-1450
INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$2
6136-72-1460
INJECTION PUMP ASS'Y,(EUROPE SPEC.)
SN: 50001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105410-6280
GOVERNOR ASS'Y
SN: 50001-UP
1шт.
|$6
DK105410-6380
GOVERNOR ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$$8
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.
-1шт.
1
DK154000-6400
HOUSING
SN: 50001-UP
1шт.
3
DK154007-2900
PLUG
SN: 50001-UP
1шт.
4
DK154007-0200
ADAPTER
SN: 50001-UP
1шт.
5
DK020018-1840
BOLT
SN: 50001-UP
1шт.
6
DK154350-1900
PLATE
SN: 50001-UP
1шт.
7
DK020006-1440
BOLT
SN: 50001-UP
6шт.
8
DK154010-0100
SCREW
SN: 50001-UP
1шт.
10
DK154050-1720
LIMITER
SN: 50001-UP
1шт.
11
DK154100-9720
FLYWEIGHT ASS'Y
SN: 50001-UP
1шт.
12
DK025803-1610
KEY, 16MM
SN: 50001-UP
1шт.
14
DK029231-2030
NUT
SN: 50001-UP
1шт.
15
DK154123-0120
SLEEVE
SN: 50001-UP
1шт.
15
DK029801-0030
BEARING
SN: 50001-UP
1шт.
16
DK029311-0180
SHIM, 0.30MM,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
-2шт.
16
DK139410-0000
SHIM, 0.50MM,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
-2шт.
16
DK029311-0210
SHIM, 1.00MM,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
-2шт.
16
DK139410-0100
SHIM, 1.50MM,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
-2шт.
16
DK139410-3100
SHIM, 3.00MM,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
-2шт.
16
DK139410-3200
SHIM, 4.00MM,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
-2шт.
18
DK154175-4620
CAPSULE,SPRING
SN: 50001-UP
1шт.
18
DK154185-2220
CAPSULE,SPRING (HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
19
DK029201-6080
NUT
SN: 50001-UP
1шт.
20
DK154211-3820
GUIDE LEVER ASS'Y
SN: 50001-UP
1шт.
21
DK154230-0120
LINK
SN: 50001-UP
1шт.
22
DK016010-0540
RING,SNAP
SN: 50001-UP
1шт.
23
DK154236-1500
LEVER,TENSION
SN: 50001-UP
1шт.
24
DK155412-5200
IMPELLER
SN: 50001-UP
1шт.
25
DK154350-7700
GASKET
SN: 50001-UP
1шт.
26
DK154179-4020
CAPSULE
SN: 50001-UP
1шт.
26
DK154179-0620
CAPSULE,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
27
DK029201-6010
NUT
SN: 50001-UP
1шт.
Выбрано товаров: 46
