Запчасти Komatsu 6D105-1N ТОПЛ. НАСОС (НАСОС) (/)(№-) ТОПЛИВН. СИСТЕМА

|$0

6136-72-1410

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$1

6136-72-1450

INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|$2

6136-72-1460

INJECTION PUMP ASS'Y,(EUROPE SPEC.)

SN: 50001-UP

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$5

DK101060-2470

PUMP ASS'Y

SN: 50001-UP

1шт.

|$$7

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A AND 0451B.

-1шт.

1

DK131071-6220

HOUSING

SN: 50001-UP

1шт.

2

DK029040-6020

STUD

SN: 50001-UP

3шт.

3

DK131400-0100

ADAPTER

SN: 50001-UP

1шт.

4

DK131420-0420

BOLT

SN: 50001-UP

1шт.

5

DK131028-6020

COVER

SN: 50001-UP

1шт.

6

DK131011-0800

GASKET

SN: 50001-UP

1шт.

7

DK131017-1000

SCREW

SN: 50001-UP

2шт.

8

DK029340-6020

GASKET

SN: 50001-UP

2шт.

9

DK139206-0400

NUT

SN: 50001-UP

3шт.

10

DK029633-1010

O-RING

SN: 50001-UP

1шт.

11

DK131370-1400

CAMSHAFT

SN: 50001-UP

1шт.

12

DK016630-2030

BEARING

SN: 50001-UP

-2шт.

12

DK028201-7020

BEARING

SN: 50001-UP

-2шт.

13

DK131302-0300

RING

SN: 50001-UP

2шт.

14

DK029311-7010

SHIM, 0.1MM

SN: 50001-UP

-2шт.

14

DK029311-7020

SHIM, 0.12MM

SN: 50001-UP

-2шт.

14

DK029311-7030

SHIM, 0.14MM

SN: 50001-UP

-2шт.

14

DK029311-7040

SHIM, 0.16MM

SN: 50001-UP

-2шт.

14

DK029311-7050

SHIM, 0.18MM

SN: 50001-UP

-2шт.

14

DK029311-7090

SHIM, 0.3MM

SN: 50001-UP

-2шт.

14

DK029311-7060

SHIM, 0.5MM

SN: 50001-UP

-2шт.

14

DK029311-7210

SHIM, 0.7MM

SN: 50001-UP

-2шт.

14

DK029311-7070

SHIM, 1.0MM

SN: 50001-UP

-2шт.

14

DK029311-7220

SHIM, 1.4MM

SN: 50001-UP

-2шт.

14

DK139417-0000

SHIM, 2.40MM

SN: 50001-UP

-2шт.

15

DK131306-0800

BEARING,CENTER

SN: 50001-UP

1шт.

16

DK029050-5010

SCREW

SN: 50001-UP

2шт.

17

DK026505-0940

GASKET

SN: 50001-UP

2шт.

18

DK029621-7050

SEAL,OIL

SN: 50001-UP

1шт.

19

DK131330-2600

COVER

SN: 50001-UP

1шт.

20

DK020006-1440

BOLT

SN: 50001-UP

4шт.

21

DK029634-4020

O-RING

SN: 50001-UP

1шт.

22

DK156635-4000

COUPLING

SN: 50001-UP

1шт.

23

DK131325-0500

NUT

SN: 50001-UP

1шт.

24

DK023641-2410

WASHER,SPRING

SN: 50001-UP

1шт.

25

DK025803-1610

KEY, 16MM

SN: 50001-UP

1шт.

26

DK029731-4680

BOLT,EYE

SN: 50001-UP

1шт.

27

DK029341-4130

GASKET

SN: 50001-UP

2шт.

28

DK029731-0120

BOLT,EYE

SN: 50001-UP

1шт.

29

DK029341-0110

GASKET

SN: 50001-UP

2шт.
