Артикул
Название
Примечание
Количество
G-1
0
ALTERNATOR GROUP
SN: 23318-UP
1шт.
|$$2
====================
-1шт.
|$$4
THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
KD1-0452-62017
BEARING,BALL¤ REAR
SN: 23318-UP
1шт.
2
KD1-33926-0252
RETAINER
SN: 23318-UP
1шт.
3
KD0-33100-1380
ROTOR ASS'Y
SN: 23318-UP
1шт.
4
KD1-33923-0940
COLLAR
SN: 23318-UP
1шт.
5
KD1-33926-0930
RETAINER
SN: 23318-UP
1шт.
6
KD1-33926-0920
RETAINER
SN: 23318-UP
1шт.
7
KD1-0452-63027
BEARING,BALL¤ FRONT
SN: 23318-UP
1шт.
8
KD1-33926-0910
RETAINER
SN: 23318-UP
1шт.
9
KD1-33926-0930
RETAINER
SN: 23318-UP
1шт.
10
KD1-33761-1170
COVER
SN: 23318-UP
1шт.
|11
KD0-33700-2590
REAR BRACKET ASS'Y
SN: 23318-UP
1шт.
11
KD1-38943-0050
BUSHING,INSULATE
SN: 23318-UP
1шт.
12
KD1-33780-0600
TERMINAL ASS'Y
SN: 23318-UP
1шт.
13
KD0-33710-3100
BRACKET,REAR
SN: 23318-UP
1шт.
14
KD0-33730-2300
RECTIFIER ASS'Y
SN: 23318-UP
1шт.
15
KD0-33719-0080
REGULATOR ASS'Y
SN: 23318-UP
1шт.
16
KD1-33200-1311
STATOR ASS'Y
SN: 23318-UP
1шт.
17
KD0-33311-0420
BRACKET,FRONT
SN: 23318-UP
1шт.
18
KD1-33421-0600
FAN
SN: 23318-UP
1шт.
19
KD0-33411-2800
PULLEY,NON HARDENING
SN: 23318-UP
1шт.
20
KD1-33951-0680
PACKING,(NOT SHOWN)
SN: 23318-UP
2шт.
|$$26
====================
-1шт.
G-1
6202-8X-6000
ALTERNATOR GROUP
|1
600-821-3860
ALTERNATOR A. (15A)
1
KD1-0452-62017
BEARING,BALL¤ REAR
2
KD1-33926-0252
RETAINER
3
KD0-33100-1380
ROTOR ASS'Y
4
KD1-33923-0940
COLLAR
5
KD1-33926-0930
RETAINER
6
KD1-33926-0920
RETAINER
7
KD1-0452-63027
BEARING,BALL¤ FRONT
8
KD1-33926-0910
RETAINER
9
KD1-33926-0930
RETAINER
10
KD1-33761-1170
COVER
|11
KD0-33700-2590
REAR BRACKET ASS'Y
11
KD1-38943-0050
BUSHING,INSULATE
12
KD1-33780-0600
TERMINAL ASS'Y
13
KD0-33710-3100
BRACKET,REAR
14
KD0-33730-2300
RECTIFIER ASS'Y
15
KD0-33719-0080
REGULATOR ASS'Y
16
KD1-33200-1311
STATOR ASS'Y
17
KD0-33311-0420
BRACKET,FRONT
18
KD1-33421-0600
FAN
19
KD0-33411-2800
PULLEY,NON HARDENING
20
KD1-33951-0680
PACKING,(NOT SHOWN)
Выбрано товаров: 49
