Артикул
Название
Примечание
Количество
|1
6202-72-1211
INJECTION PUMP ASS'Y
SN: .-UP
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 23318-.
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK101045-8100
PUMP ASS'Y
SN: .-UP
1шт.
|1
DK101045-8070
PUMP ASS'Y
SN: 23318-.
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131063-8320
HOUSING
SN: 23318-UP
1шт.
2
DK029040-6020
STUD
SN: 23318-UP
3шт.
3
DK131400-0100
ADAPTER
SN: 23318-UP
1шт.
4
DK131002-2000
ADAPTER
SN: 23318-UP
1шт.
5
DK131028-6220
COVER
SN: 23318-UP
1шт.
6
DK131011-1900
GASKET
SN: .-UP
1шт.
7
DK131017-1000
SCREW
SN: 23318-UP
2шт.
9
DK139206-0400
NUT
SN: 23318-UP
3шт.
11
DK131360-2800
CAMSHAFT
SN: .-UP
1шт.
|11
DK131360-0800
CAMSHAFT
SN: 23318-.
1шт.
|12
DK028201-7020
BEARING
SN: 23318-UP
-2шт.
13
DK131302-0300
RING
SN: 23318-UP
2шт.
14
DK029311-7010
SHIM¤ 0.1MM
SN: 23318-UP
-2шт.
|14
DK029311-7020
SHIM¤ 0.12MM
SN: 23318-UP
-2шт.
|14
DK029311-7030
SHIM¤ 0.14MM
SN: 23318-UP
-2шт.
|14
DK029311-7040
SHIM¤ 0.16MM
SN: 23318-UP
-2шт.
|14
DK029311-7050
SHIM¤ 0.18MM
SN: 23318-UP
-2шт.
|14
DK029311-7090
SHIM¤ 0.3MM
SN: 23318-UP
-2шт.
|14
DK029311-7060
SHIM¤ 0.5MM
SN: 23318-UP
-2шт.
|14
DK029311-7210
SHIM¤ 0.7MM
SN: 23318-UP
-2шт.
|14
DK029311-7070
SHIM¤ 1.0MM
SN: 23318-UP
-2шт.
|14
DK029311-7220
SHIM¤ 1.4MM
SN: 23318-UP
-2шт.
|14
DK139417-0000
SHIM¤ 2.40MM
SN: .-UP
-2шт.
15
DK029621-7050
SEAL,OIL
SN: 23318-UP
1шт.
16
DK131330-6200
COVER
SN: 23318-UP
1шт.
17
DK020006-1440
BOLT
SN: 23318-UP
4шт.
18
DK025803-1640
KEY
SN: 23318-UP
1шт.
19
DK131401-0020
BOLT,EYE
SN: .-UP
1шт.
|19
DK029731-4680
BOLT,EYE
SN: 23318-.
1шт.
21
DK131424-7420
VALVE,OVER FLOW
SN: .-UP
1шт.
22
DK131508-8920
EYE
SN: 23318-UP
1шт.
|1
6202-72-1211
INJECTION PUMP ASS'Y
|1
6202-72-1210
INJECTION PUMP ASS'Y
|1
DK101045-8100
PUMP ASS'Y
|1
DK101045-8070
PUMP ASS'Y
1
DK131063-8320
HOUSING
2
DK029040-6020
STUD
3
DK131400-0100
ADAPTER
4
DK131002-2000
ADAPTER
5
DK131028-6220
COVER
6
DK131011-1900
GASKET
7
DK131017-1000
SCREW
8
DK029340-6020
GASKET
9
DK139206-0400
NUT
10
DK029633-1010
O-RING
11
DK131360-2800
CAMSHAFT
|11
DK131360-0800
CAMSHAFT
12
DK016630-2030
BEARING
|12
DK028201-7020
BEARING
13
DK131302-0300
RING
14
DK029311-7010
SHIM¤ 0.1MM
|14
DK029311-7020
SHIM¤ 0.12MM
|14
DK029311-7030
SHIM¤ 0.14MM
|14
DK029311-7040
SHIM¤ 0.16MM
|14
DK029311-7050
SHIM¤ 0.18MM
|14
DK029311-7090
SHIM¤ 0.3MM
|14
DK029311-7060
SHIM¤ 0.5MM
|14
DK029311-7210
SHIM¤ 0.7MM
|14
DK029311-7070
SHIM¤ 1.0MM
|14
DK029311-7220
SHIM¤ 1.4MM
|14
DK139417-0000
SHIM¤ 2.40MM
15
DK029621-7050
SEAL,OIL
16
DK131330-6200
COVER
17
DK020006-1440
BOLT
18
DK025803-1640
KEY
19
DK131401-0020
BOLT,EYE
|19
DK029731-4680
BOLT,EYE
20
DK029341-4130
GASKET
21
DK131424-7420
VALVE,OVER FLOW
|21
DK131424-1520
VALVE,OVER FLOW
22
DK131508-8920
EYE
23
DK029341-4130
GASKET
24
DK029731-0120
BOLT,EYE
25
DK029341-0110
GASKET
Выбрано товаров: 89
