Запчасти Komatsu 4D95S-W-1F-PL СТАРТЕР (.8KW) ЭЛЕКТРИКА

|1

600-813-3170

STARTING MOTOR ASS'Y,(2.8KW)

SN: 23318-UP

1шт.

|$$2

THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

KD1-23100-0170

ARMATURE ASS'Y

SN: 23318-UP

1шт.

2

KD1-0454-60037

BEARING,BALL¤ FRONT

SN: 23318-UP

1шт.

3

KD1-0454-06087

BEARING,BALL¤ REAR

SN: 23318-UP

1шт.

4

KD0-23200-0240

YOKE ASS'Y

SN: 23318-UP

1шт.

5

KD1-23740-0150

BRUSH ASS'Y

SN: 23318-UP

2шт.

6

KD1-23310-0550

FRONT BRACKET ASS'Y

SN: 23318-UP

1шт.

7

KD7-23351-0160

METAL

SN: 23318-UP

1шт.

8

KD7-23320-0030

SHIFT LEVER ASS'Y

SN: 23318-UP

1шт.

9

KD0-47100-3590

MAGNETIC SWITCH A.

SN: 23318-UP

1шт.

10

KD1-23111-0370

SHAFT ASS'Y

SN: 23318-UP

1шт.

11

KD1-23181-0050

STOPPER,PINION

SN: 23318-UP

1шт.

12

KD1-09066-0050

RING,CLIP

SN: 23318-UP

1шт.

13

KD0-23500-0350

CLUTCH ASS'Y,OVER RUNNING

SN: 23318-UP

1шт.

14

KD1-23611-0460

BRACKET,CENTER

SN: 23318-UP

1шт.

15

KD0-23600-0170

CENTER BRACKET A.

SN: 23318-UP

1шт.

16

KD7-23351-0150

METAL

SN: 23318-UP

1шт.

17

KD1-0240-06355

BOLT

SN: 23318-UP

2шт.

|18

KD7-23700-0220

REAR BRACKET ASS'Y

SN: 23318-UP

1шт.

18

KD1-23711-0180

BRACKET,REAR

SN: 23318-UP

1шт.

19

KD0-23913-0080

SPRING,BRUSH

SN: 23318-UP

4шт.

20

KD0-23750-0160

BRUSH HOLDER A.

SN: 23318-UP

1шт.

21

KD1-23740-0140

BRUSH ASS'Y

SN: 23318-UP

2шт.

22

KD1-23901-0080

BOLT

SN: 23318-UP

2шт.

23

KD0-25000-6970

SWITCH ASS'Y

SN: 23318-UP

1шт.

24

KD7-09210-1400

SEAL ASS'Y,(NOT SHOWN)

SN: 23318-UP

1шт.
