|1
6204-13-1100
CYLINDER HEAD ASS'Y,VALVE LESS
SN: 198831-UP
1шт.
1
0
HEAD,CYLINDER
SN: 198831-UP
1шт.
2
6204-19-1310
GUIDE,VALVE
SN: 198831-UP
8шт.
3
07046-41810
PLUG
SN: 198831-UP
9шт.
4
07046-42216
PLUG
SN: 198831-UP
3шт.
5
07046-42516
PLUG
SN: 198831-UP
11шт.
6
02720-40104
PLUG
SN: 198831-UP
1шт.
7
6204-11-8910
PIPE,BREATHER
SN: 198831-UP
2шт.
8
6207-41-4110
VALVE,INTAKE
SN: 198831-UP
4шт.
9
6204-43-4210
VALVE,EXHAUST
SN: 198831-UP
4шт.
10
6204-41-4510
SEAT,SPRING
SN: 198831-UP
8шт.
11
6204-41-4520
COTTER
SN: 198831-UP
16шт.
12
6204-41-4431
SPRING,VALVE
SN: 198831-UP
8шт.
13
6204-41-4540
SEAL,VALVE (K1)
SN: 198831-UP
8шт.
14
6204-41-4550
CAP,VALVE STEM
SN: 198831-UP
8шт.
15
6204-11-1830
GASKET,HEAD (K1)
SN: 198831-UP
1шт.
16
6204-13-1610
BOLT
SN: 198831-UP
17шт.
17
01643-51232
WASHER
SN: 198831-UP
17шт.
18
6207-11-1430
SEAT,INTAKE VALVE (SERVICE PARTS) (STD)
SN: 198831-UP
4шт.
|18
6207-19-1430
SEAT¤ 0.25MM,INTAKE VALVE (SERVICE PARTS) (OS)
SN: 198831-UP
4шт.
|18
6207-18-1430
SEAT¤ 0.50MM,INTAKE VALVE (SERVICE PARTS) (OS)
SN: 198831-UP
4шт.
19
6204-11-1440
SEAT,EXHAUST VALVE (SERVICE PARTS) (STD)
SN: 198831-UP
4шт.
|19
6204-19-1440
SEAT¤ 0.25MM,EXHAUST VALVE (SERVICE PARTS) (OS)
SN: 198831-UP
4шт.
|19
6204-18-1440
SEAT¤ 0.50MM,EXHAUST VALVE (SERVICE PARTS) (OS)
SN: 198831-UP
4шт.
