Запчасти Komatsu 4D95LE-1A ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|1

6204-13-1100

CYLINDER HEAD ASS'Y,VALVE LESS

SN: 198831-UP

1шт.

1

0

HEAD,CYLINDER

SN: 198831-UP

1шт.

2

6204-19-1310

GUIDE,VALVE

SN: 198831-UP

8шт.

3

07046-41810

PLUG

SN: 198831-UP

9шт.

4

07046-42216

PLUG

SN: 198831-UP

3шт.

5

07046-42516

PLUG

SN: 198831-UP

11шт.

6

02720-40104

PLUG

SN: 198831-UP

1шт.

7

6204-11-8910

PIPE,BREATHER

SN: 198831-UP

2шт.

8

6207-41-4110

VALVE,INTAKE

SN: 198831-UP

4шт.

9

6204-43-4210

VALVE,EXHAUST

SN: 198831-UP

4шт.

10

6204-41-4510

SEAT,SPRING

SN: 198831-UP

8шт.

11

6204-41-4520

COTTER

SN: 198831-UP

16шт.

12

6204-41-4431

SPRING,VALVE

SN: 198831-UP

8шт.

13

6204-41-4540

SEAL,VALVE (K1)

SN: 198831-UP

8шт.

14

6204-41-4550

CAP,VALVE STEM

SN: 198831-UP

8шт.

15

6204-11-1830

GASKET,HEAD (K1)

SN: 198831-UP

1шт.

16

6204-13-1610

BOLT

SN: 198831-UP

17шт.

17

01643-51232

WASHER

SN: 198831-UP

17шт.

18

6207-11-1430

SEAT,INTAKE VALVE (SERVICE PARTS) (STD)

SN: 198831-UP

4шт.

|18

6207-19-1430

SEAT¤ 0.25MM,INTAKE VALVE (SERVICE PARTS) (OS)

SN: 198831-UP

4шт.

|18

6207-18-1430

SEAT¤ 0.50MM,INTAKE VALVE (SERVICE PARTS) (OS)

SN: 198831-UP

4шт.

19

6204-11-1440

SEAT,EXHAUST VALVE (SERVICE PARTS) (STD)

SN: 198831-UP

4шт.

|19

6204-19-1440

SEAT¤ 0.25MM,EXHAUST VALVE (SERVICE PARTS) (OS)

SN: 198831-UP

4шт.

|19

6204-18-1440

SEAT¤ 0.50MM,EXHAUST VALVE (SERVICE PARTS) (OS)

SN: 198831-UP

4шт.
