Артикул
Название
Примечание
Количество
|1
6204-72-1330
INJECTION PUMP A.
SN: 11437-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK101045-8050
PUMP ASS'Y
SN: 11437-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131063-7220
HOUSING
SN: 11437-UP
1шт.
3
DK131400-0100
ADAPTER
SN: 11437-UP
1шт.
4
DK131420-0420
BOLT
SN: 11437-UP
1шт.
5
DK131028-6220
COVER
SN: 11437-UP
1шт.
6
DK131017-1000
SCREW
SN: 11437-UP
2шт.
8
DK139206-0400
NUT
SN: 11437-UP
3шт.
10
DK131360-0800
CAMSHAFT
SN: 11437-UP
1шт.
|11
DK028201-7020
BEARING
SN: 11437-UP
-2шт.
12
DK131302-0300
RING
SN: 11437-UP
2шт.
13
DK029311-7010
SHIM¤ 0.1MM
SN: 11437-UP
-2шт.
|13
DK029311-7020
SHIM¤ 0.12MM
SN: 11437-UP
-2шт.
|13
DK029311-7030
SHIM¤ 0.14MM
SN: 11437-UP
-2шт.
|13
DK029311-7040
SHIM¤ 0.16MM
SN: 11437-UP
-2шт.
|13
DK029311-7050
SHIM¤ 0.18MM
SN: 11437-UP
-2шт.
|13
DK029311-7090
SHIM¤ 0.3MM
SN: 11437-UP
-2шт.
|13
DK029311-7060
SHIM¤ 0.5MM
SN: 11437-UP
-2шт.
|13
DK029311-7210
SHIM¤ 0.7MM
SN: 11437-UP
-2шт.
|13
DK029311-7070
SHIM¤ 1.0MM
SN: 11437-UP
-2шт.
|13
DK029311-7220
SHIM¤ 1.4MM
SN: 11437-UP
-2шт.
14
DK029621-7050
SEAL,OIL
SN: 11437-UP
1шт.
15
DK131330-2200
COVER
SN: 11437-UP
1шт.
16
DK020006-1440
BOLT
SN: 11437-UP
4шт.
17
DK025803-1640
KEY
SN: 11437-UP
1шт.
|1
6204-72-1330
INJECTION PUMP A.
SN: 11437-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK101045-8050
PUMP ASS'Y
SN: 11437-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.
-1шт.
1
DK131063-7220
HOUSING
SN: 11437-UP
1шт.
3
DK131400-0100
ADAPTER
SN: 11437-UP
1шт.
4
DK131420-0420
BOLT
SN: 11437-UP
1шт.
5
DK131028-6220
COVER
SN: 11437-UP
1шт.
6
DK131017-1000
SCREW
SN: 11437-UP
2шт.
8
DK139206-0400
NUT
SN: 11437-UP
3шт.
10
DK131360-0800
CAMSHAFT
SN: 11437-UP
1шт.
|11
DK028201-7020
BEARING
SN: 11437-UP
-2шт.
12
DK131302-0300
RING
SN: 11437-UP
2шт.
13
DK029311-7010
SHIM¤ 0.1MM
SN: 11437-UP
-2шт.
|13
DK029311-7020
SHIM¤ 0.12MM
SN: 11437-UP
-2шт.
|13
DK029311-7030
SHIM¤ 0.14MM
SN: 11437-UP
-2шт.
|13
DK029311-7040
SHIM¤ 0.16MM
SN: 11437-UP
-2шт.
|13
DK029311-7050
SHIM¤ 0.18MM
SN: 11437-UP
-2шт.
|13
DK029311-7090
SHIM¤ 0.3MM
SN: 11437-UP
-2шт.
|13
DK029311-7060
SHIM¤ 0.5MM
SN: 11437-UP
-2шт.
|13
DK029311-7210
SHIM¤ 0.7MM
SN: 11437-UP
-2шт.
|13
DK029311-7070
SHIM¤ 1.0MM
SN: 11437-UP
-2шт.
|13
DK029311-7220
SHIM¤ 1.4MM
SN: 11437-UP
-2шт.
14
DK029621-7050
SEAL,OIL
SN: 11437-UP
1шт.
15
DK131330-2200
COVER
SN: 11437-UP
1шт.
16
DK020006-1440
BOLT
SN: 11437-UP
4шт.
17
DK025803-1640
KEY
SN: 11437-UP
1шт.
Выбрано товаров: 72
